Item no. Part no. Part name Service part
1 9323834132 Heat exchanger unit ♦
2 9377840004 Protective net ♦
3 9322556028 Top panel assy ♦
4 9322138002 Thermistor holder ♦
5 9900984014 Thermistor (Heat exchanger) ♦
6 313728262708 Thermistor spring A ♦
7 9300089012 Thermistor spring ♦
8 9900935047 Thermistor assy (Discharge temp.) ♦
9 9709686218 Main PCB ♦
10 9900565060 Thermistor (Outdoor temp.) ♦
11 9384912008 Heat sink ♦
12 9900583019 Reactor assy ♦
13 9322552259 Cabinet right assy ♦
14 9384268006 Conduit cover ♦
15 9322570055 Switch cover assy ♦
16 9383720000 Drain cap assy ♦
17 9322144003 Drain pipe ♦
18 9323550025 Base assy ♦
19 9317903011 Emblem ♦
20 9322555199 Front panel assy ♦
21 9384265005 Fan guard ♦
22 9322136008 Propeller fan ♦
23 9603553005 DC fan motor ♦
24 9322553010 Motor bracket assy ♦
— 9711555007
→ire with terminal
(Terminal—Earth)
♦
a — Hair pin cushion —
3-1. Model: AOUH09LUAS1 - (02-11) - 3. Outdoor unit parts list
