Item no. Part no. Part name Service part
1
9323834194 Heat exchanger unit (12 model) ♦
9323834330 Heat exchanger unit (18 model) ♦
2 9377854001 Protective net assy ♦
3 9322556028 Top panel assy ♦
4 9322327000 Thermistor holder ♦
5 9900984014 Thermistor (Heat exchanger) ♦
6 313728262708 Thermistor spring A ♦
7 9300089012 Thermistor spring ♦
8 9900935054 Thermistor assy (Discharge temp.) ♦
9
9709686225 Main PCB (12 model) ♦
9709686232 Main PCB (18 model) ♦
10 9900985011 Thermistor assy (Compressor temp.) ♦
11 9900565060 Thermistor assy (Outdoor temp.) ♦
12 9322420046 Heat sink ♦
13 9322552242 Cabinet right assy ♦
14 9384276001 Conduit cover ♦
15 9322570062 Switch cover assy ♦
16 9810028006 Thermistor stopper ♦
17 9383720000 Drain cap assy ♦
18 9322144003 Drain pipe ♦
19 9323550025 Base assy ♦
20 9317903011 Emblem ♦
21 9322555182 Front panel assy ♦
22 9384273000 Fan Guard ♦
23 9322150004 Propeller fan ♦
24 9603601003 DC fan motor ♦
25 9322553027 Motor bracket assy ♦
— 9709488027
→ire with terminal
(Terminal—Earth)
♦
a — Hair pin cushion —
3-2. Models: AOUH12LUAS1 and AOUH18LUAS1 - (02-15) - 3. Outdoor unit parts list
