Item no. Part no. Part name Service part
50
9323825208 Compressor unit (12 model) ♦
9323825215 Compressor unit (18 model) ♦
51 9322446015 4-way valve assy ♦
52 9970194023 Solenoid ♦
53 9970173028 Expansion valve coil ♦
54 9322463029 Pulse motor valve assy ♦
55 9322474001 2-way valve assy ♦
56
9322850010 3-way valve assy (12 model) ♦
9387831016 3-way valve assy (18 model) ♦
57 9322824004 S-insulator K ♦
58 9323045002 S-insulator V ♦
59 9322501004 S-insulator H ♦
60 9322847003 S-insulator F ♦
61 9324014014 S-insulator B ♦
a — Valve bracket —
b — Muffler —
3-2. Models: AOUH12LUAS1 and AOUH18LUAS1 - (02-17) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
