Model: ARXG22KHTAP
AFR
m
3
/h
1,050
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 4.99 4.27 0.55 5.56 4.30 0.56 5.75 4.67 0.56 6.13 4.69 0.57 6.32 5.06 0.57 6.70 5.04 0.58 7.08 5.37 0.58
-10 5.03 4.28 0.46 5.61 4.30 0.47 5.80 4.68 0.47 6.18 4.69 0.48 6.37 5.07 0.48 6.75 5.05 0.48 7.13 5.38 0.49
0 4.91 4.21 0.47 5.46 4.24 0.48 5.65 4.61 0.48 6.02 4.62 0.49 6.21 4.99 0.49 6.58 4.97 0.49 6.96 5.29 0.50
5 4.77 4.16 0.60 5.32 4.19 0.61 5.50 4.55 0.61 5.86 4.57 0.62 6.04 4.93 0.62 6.40 4.91 0.63 6.76 5.23 0.63
10 4.74 4.14 0.59 5.28 4.17 0.60 5.46 4.53 0.60 5.82 4.55 0.61 6.00 4.91 0.61 6.36 4.89 0.62 6.72 5.21 0.62
15 4.59 4.08 0.70 5.11 4.10 0.72 5.29 4.46 0.72 5.64 4.47 0.73 5.81 4.83 0.73 6.16 4.81 0.74 6.51 5.12 0.74
20 5.77 4.65 1.25 6.43 4.68 1.27 6.65 5.09 1.28 7.09 5.10 1.29 7.31 5.51 1.30 7.75 5.49 1.31 8.19 5.85 1.33
25 5.43 4.51 1.39 6.05 4.53 1.41 6.25 4.93 1.42 6.66 4.94 1.43 6.87 5.34 1.44 7.28 5.32 1.45 7.69 5.67 1.47
30 5.08 4.35 1.52 5.66 4.37 1.55 5.85 4.75 1.56 6.24 4.77 1.57 6.43 5.15 1.58 6.82 5.13 1.60 7.20 5.46 1.61
35 4.74 4.20 1.65 5.28 4.23 1.68 5.46 4.60 1.68 5.82 4.61 1.70 6.00 4.98 1.71 6.36 4.96 1.73 6.72 5.28 1.74
40 4.50 4.08 1.79 5.01 4.10 1.82 5.18 4.46 1.83 5.52 4.47 1.84 5.69 4.83 1.85 6.03 4.81 1.87 6.37 5.12 1.89
46 3.69 3.60 1.54 4.11 3.63 1.56 4.25 3.94 1.57 4.53 3.95 1.59 4.67 4.27 1.59 4.95 4.25 1.61 5.23 4.53 1.63
- 10 -
4-1. Cooling capacity
4. Capacity table
DUCT TYPE
ARXG12-22KHTAP
DUCT TYPE
ARXG12-22KHTAP
