Fujitsu AO G12KBTB Series Design & Technical Manual

1. Specifications
Type
Duct
Inverter heat pump
Model name ARXG12KHTAP ARXG14KHTAP ARXG18KHTAP ARXG22KHTAP
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 3.5 4.3 5.2 6.0
Btu/h 11,950 14,650 17,700 20,500
Min.—Max.
kW 0.9 — 4.4 0.9 — 5.4 0.9 — 5.9 0.9 — 6.7
Btu/h 3,100 — 15,000 3,100 — 18,400 3,100 — 20,100 3,100 — 22,900
Heating
Rated
kW 4.1 5.0 6.0 7.0
Btu/h 14,000 17,050 20,500 23,900
Min.—Max.
kW 0.9 — 5.7 0.9 — 6.5 0.9 — 7.5 0.9 — 8.0
Btu/h 3,100 — 19,400 3,100 - 22,100 3,100 — 25,600 3,100 — 27,300
Input power
Cooling
Rated
kW
0.87 1.17 1.36 1.71
Max. 2.24 2.35 2.79 2.80
Heating
Rated 1.00 1.25 1.56 1.81
Max. 2.24 2.35 2.79 2.80
Current
Cooling
Rated A
3.9 5.1 6.0 7.5
Heating 4.4 5.5 6.8 7.9
Power factor
Cooling
%
97.0 99.7 98.6 99.1
Heating 98.8 98.8 99.7 99.6
EER Cooling
kW/kW
4.02 3.68 3.82 3.51
COP Heating 4.10 4.00 3.85 3.87
Moisture removal L/h (pints/h) 0.7 (1.2) 0.9 (1.6) 1.2 (2.1) 1.5 (2.6)
Maximum operating current *1
Cooling
A
9.7 10.2 12.1 12.6
Heating 9.7 10.2 12.1 12.6
Fan
Airflow rate
Cooling
HIGH
m
3
/h
850 950 1,050 1,050
MED 680 760 840 840
LOW 590 670 740 740
QUIET 510 570 630 630
Heating
HIGH 850 950 1,050 1,050
MED 680 760 840 840
LOW 590 670 740 740
QUIET 510 570 630 630
Type × Q'ty Sirocco fan × 1 Sirocco fan × 2
Motor output W 154 197
Recommended static pressure range Pa 30 to 200
Sound pressure level *2
Cooling
HIGH
dB (A)
32 33 28 28
MED 27 28 25 25
LOW 26 27 22 22
QUIET 24 25 20 20
Heating
HIGH 32 33 28 28
MED 27 28 25 25
LOW 26 27 22 22
QUIET 24 25 20 20
Heat exchanger type
Dimensions (H × W × D)
mm
420 × 458 × 39.9 420 × 758 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 20
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Steel sheet
Color ―
Dimensions
(H × W × D)
Net
mm
300 × 700 × 700 300 × 1,000 × 700
Gross 400 × 938 × 875 400 × 1,238 × 875
Weight
Net
kg
27 35
Gross 34 44
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Drain port
Material PVC
Size mm Ø 26 (I.D.), Ø 32 (O.D.)
Drain hose
Material PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote control (Option)
Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair
™
)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Standard static pressure; 35 Pa
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play
™
store or on App Store
®
. Optional WLAN adapter is also required. For details, refer to the setting manual.
- 2 -
1. Specifications
DUCT TYPE ARXG12-22KHTAP DUCT TYPE ARXG12-22KHTAP

Fujitsu AO G12KBTB Series Specifications

General

Brand	Fujitsu
Model	AO G12KBTB Series
Category	Air Conditioner
Language	English
