Fujitsu AO G12KBTB Series Design & Technical Manual

10. Electrical characteristics
Model name AOYG12KBTB AOYG14KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 9.7 10.2
Starting current A 4.8 5.8
Wiring
spec.
*2
Circuit breaker current A 13
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 26
Model name AOYG18KBTB AOYG22KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 12.1 12.6
Starting current A 7.1 8.2
Wiring
spec.
*2
Circuit breaker current A 16
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 31
*1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
