Fujitsu AO G12KBTB Series Design & Technical Manual

5. Fan performance
5-1. Fan performance curve
¢ Model: ARXG12KHTAP
[l/s]
[m
3
/h]
Airflow
139 278 417 556
500
0
0 1,000 1,500 2,000
0
280
300
260
240
220
200
180
160
140
120
100
80
60
40
20
External Static Pressure [Pa]
Fan performance curve_1
Hi (Normal SP)
Qu (Normal SP)
Hi (SP mode20)
SP mode20
upper limit
Normal SP
upper limit
Normal SP
lower limit
Qu(SP mode20)
SP mode20
lower limit
Fan performance curve_2
(For function setting by remote controller)
[l/s]
[m
3
/h]
Airflow
139 278 417 556
500
0
0 1,000 1,500 2,000
280
300
260
240
220
200
180
160
140
120
100
80
60
40
20
External Static Pressure [Pa]
Hi (SP mode06)
Hi (SP mode04)
Hi (SP mode08)
Hi (SP mode10)
Hi (SP mode12)
Hi (SP mode14)
Hi (SP mode16)
Hi (SP mode18)
Hi (SP mode20)
Hi (SP mode07)
Hi (SP mode05)
Hi (
Normal SP)
Hi (SP mode09)
Hi (SP mode11)
Hi (SP mode13)
Hi (SP mode15)
Hi (SP mode17)
Hi (SP mode19)
Hi (SP mode03)
NOTES:
• Setting of the external static pressure is switchable into modes by using the remote controller.
• According to the resistance of the connecting duct, perform the setting of the external static
pressure with referring “Fan performance curve_2” above.
• The default setting is set at "Normal SP".
- 12 -
5-1. Fan performance curve
5. Fan performance
DUCT TYPE ARXG12-22KHTAP DUCT TYPE ARXG12-22KHTAP
