Fujitsu AO G12KBTB Series Design & Technical Manual

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ARXG12KHTAP
AFR
m
3
/h
850
Indoor temperature
°CDB 16 18 20 22 27
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 3.87 1.43 3.78 1.46 3.69 1.49 3.60 1.52 3.51 1.55
-10 -11 4.35 1.50 4.24 1.53 4.14 1.56 4.04 1.59 3.93 1.62
-5 -7 4.83 1.56 4.72 1.60 4.60 1.63 4.49 1.66 4.37 1.70
0 -2 5.31 1.62 5.19 1.66 5.06 1.69 4.93 1.72 4.81 1.76
5 3 5.79 1.69 5.65 1.72 5.51 1.76 5.37 1.80 5.23 1.83
7 6 5.99 1.71 5.84 1.74 5.70 1.78 5.56 1.82 5.42 1.85
10 8 6.13 1.67 5.99 1.71 5.84 1.74 5.69 1.77 5.55 1.81
15 10 6.37 1.61 6.22 1.65 6.07 1.68 5.92 1.71 5.77 1.74
20 15 6.15 1.32 6.01 1.35 5.86 1.38 5.71 1.41 5.57 1.43
24 18 6.09 1.17 5.95 1.20 5.80 1.22 5.66 1.24 5.51 1.26
¢
Model: ARXG14KHTAP
AFR
m
3
/h
950
Indoor temperature
°CDB 16 18 20 22 27
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 4.54 1.72 4.43 1.75 4.32 1.79 4.21 1.83 4.10 1.86
-10 -11 5.05 1.77 4.93 1.80 4.81 1.84 4.69 1.88 4.57 1.91
-5 -7 5.58 1.80 5.44 1.84 5.31 1.88 5.18 1.92 5.04 1.96
0 -2 6.09 1.84 5.95 1.88 5.80 1.92 5.66 1.96 5.51 2.00
5 3 6.62 1.89 6.46 1.93 6.30 1.97 6.14 2.01 5.99 2.05
7 6 6.83 1.90 6.66 1.94 6.50 1.98 6.34 2.02 6.18 2.06
10 8 6.96 1.83 6.80 1.87 6.63 1.91 6.46 1.95 6.30 1.99
15 10 7.21 1.74 7.04 1.77 6.87 1.81 6.70 1.85 6.53 1.87
20 15 7.09 1.48 6.92 1.51 6.75 1.54 6.58 1.57 6.41 1.59
24 18 7.47 1.48 7.29 1.51 7.11 1.54 6.93 1.57 6.75 1.59
¢
Model: ARXG18KHTAP
AFR
m
3
/h
1,050
Indoor temperature
°CDB 16 18 20 22 27
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.05 1.63 4.93 1.67 4.81 1.70 4.69 1.73 4.57 1.77
-10 -11 5.69 1.75 5.56 1.78 5.42 1.82 5.28 1.86 5.15 1.89
-5 -7 6.33 1.85 6.18 1.89 6.03 1.93 5.88 1.97 5.73 2.01
0 -2 6.97 1.96 6.81 2.00 6.64 2.04 6.47 2.08 6.31 2.12
5 3 7.61 2.06 7.43 2.11 7.25 2.15 7.07 2.19 6.89 2.24
7 6 7.88 2.10 7.69 2.15 7.50 2.19 7.31 2.23 7.13 2.28
10 8 8.51 2.18 8.30 2.22 8.10 2.27 7.90 2.32 7.70 2.36
15 10 8.46 1.92 8.26 1.96 8.06 2.00 7.86 2.04 7.66 2.07
20 15 7.96 1.52 7.77 1.55 7.58 1.58 7.39 1.61 7.20 1.64
24 18 8.40 1.51 8.20 1.54 8.00 1.57 7.80 1.60 7.60 1.63
¢
Model: ARXG22KHTAP
AFR
m
3
/h
1,050
Indoor temperature
°CDB 16 18 20 22 27
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.60 2.09 5.46 2.14 5.33 2.18 5.20 2.22 5.06 2.27
-10 -11 6.14 2.17 6.00 2.21 5.85 2.26 5.70 2.31 5.56 2.35
-5 -7 6.70 2.25 6.54 2.29 6.38 2.34 6.22 2.39 6.06 2.43
0 -2 7.26 2.32 7.08 2.37 6.91 2.42 6.74 2.47 6.56 2.52
5 3 7.81 2.40 7.63 2.45 7.44 2.50 7.25 2.55 7.07 2.60
7 6 8.40 2.40 8.20 2.45 8.00 2.50 7.80 2.55 7.60 2.60
10 8 8.05 2.27 7.86 2.31 7.67 2.36 7.48 2.41 7.29 2.45
15 10 7.49 2.04 7.31 2.09 7.13 2.13 6.95 2.17 6.77 2.20
20 15 7.04 1.74 6.87 1.77 6.70 1.81 6.53 1.85 6.37 1.87
24 18 7.32 1.72 7.14 1.75 6.97 1.79 6.80 1.83 6.62 1.85
- 11 -
4-2. Heating capacity
4. Capacity table
DUCT TYPE ARXG12-22KHTAP DUCT TYPE ARXG12-22KHTAP
