Fujitsu AO G12KBTB Series Design & Technical Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model: ARXG12KHTAP
AFR
m
3
/h
850
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 2.92 2.80 0.66 3.25 2.82 0.67 3.36 3.06 0.67 3.58 3.07 0.68 3.69 3.32 0.68 3.91 3.31 0.69 4.13 3.52 0.69
-10 3.11 2.90 0.55 3.47 2.92 0.56 3.59 3.18 0.56 3.82 3.19 0.57 3.94 3.44 0.57 4.18 3.43 0.58 4.41 3.65 0.58
0 3.45 3.08 0.37 3.85 3.10 0.37 3.98 3.37 0.37 4.24 3.38 0.38 4.37 3.65 0.38 4.63 3.64 0.38 4.89 3.87 0.39
5 3.31 3.00 0.43 3.69 3.01 0.44 3.81 3.28 0.44 4.06 3.29 0.45 4.19 3.55 0.45 4.44 3.54 0.45 4.69 3.77 0.46
10 3.39 3.02 0.44 3.78 3.04 0.45 3.90 3.30 0.45 4.16 3.32 0.46 4.29 3.58 0.46 4.55 3.57 0.46 4.80 3.80 0.47
15 3.29 2.97 0.52 3.67 2.99 0.53 3.79 3.25 0.53 4.04 3.26 0.54 4.17 3.52 0.54 4.42 3.51 0.55 4.67 3.73 0.55
20 3.29 2.99 0.58 3.67 3.01 0.59 3.79 3.27 0.59 4.04 3.28 0.60 4.17 3.54 0.60 4.42 3.53 0.61 4.67 3.76 0.61
25 3.11 2.85 0.67 3.47 2.87 0.68 3.59 3.12 0.68 3.82 3.13 0.69 3.94 3.38 0.69 4.18 3.37 0.70 4.41 3.59 0.70
30 2.94 2.71 0.76 3.27 2.73 0.77 3.39 2.96 0.78 3.61 2.97 0.79 3.72 3.21 0.79 3.94 3.20 0.80 4.17 3.41 0.81
35 2.77 2.57 0.84 3.08 2.59 0.85 3.19 2.82 0.86 3.40 2.82 0.87 3.50 3.05 0.87 3.71 3.04 0.88 3.92 3.24 0.89
40 2.68 2.53 0.94 2.98 2.55 0.95 3.08 2.77 0.96 3.29 2.78 0.97 3.39 3.00 0.97 3.59 2.99 0.98 3.80 3.18 0.99
46 2.36 2.36 0.93 2.63 2.51 0.94 2.72 2.72 0.95 2.90 2.74 0.96 2.99 2.96 0.96 3.17 2.95 0.97 3.35 3.14 0.98
¢
Model: ARXG14KHTAP
AFR
m
3
/h
950
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 3.32 3.13 0.90 3.70 3.15 0.91 3.82 3.42 0.92 4.07 3.44 0.93 4.20 3.71 0.93 4.45 3.70 0.94 4.70 3.94 0.95
-10 3.60 3.27 0.58 4.01 3.29 0.59 4.15 3.57 0.59 4.42 3.58 0.60 4.56 3.87 0.60 4.83 3.85 0.61 5.11 4.11 0.61
0 3.74 3.34 0.41 4.17 3.36 0.42 4.31 3.66 0.42 4.60 3.67 0.43 4.74 3.96 0.43 5.02 3.94 0.43 5.31 4.20 0.44
5 3.56 3.24 0.50 3.97 3.26 0.51 4.10 3.54 0.51 4.37 3.56 0.52 4.51 3.84 0.52 4.78 3.82 0.53 5.05 4.07 0.53
10 3.61 3.20 0.50 4.02 3.22 0.51 4.16 3.50 0.51 4.43 3.51 0.52 4.57 3.79 0.52 4.84 3.77 0.53 5.12 4.02 0.53
15 3.55 3.21 0.60 3.95 3.23 0.61 4.09 3.51 0.61 4.36 3.52 0.62 4.49 3.80 0.62 4.76 3.78 0.63 5.03 4.03 0.63
20 3.94 3.44 0.80 4.39 3.46 0.81 4.54 3.77 0.82 4.84 3.78 0.83 4.99 4.08 0.83 5.29 4.06 0.84 5.59 4.33 0.85
25 3.76 3.34 0.92 4.19 3.36 0.93 4.33 3.66 0.94 4.62 3.67 0.95 4.76 3.96 0.95 5.05 3.94 0.96 5.33 4.20 0.97
30 3.58 3.22 1.02 3.99 3.24 1.04 4.12 3.53 1.04 4.39 3.54 1.05 4.53 3.82 1.06 4.80 3.80 1.07 5.07 4.05 1.08
35 3.40 3.12 1.13 3.78 3.14 1.15 3.91 3.42 1.15 4.17 3.43 1.16 4.30 3.70 1.17 4.56 3.69 1.18 4.82 3.93 1.19
40 3.25 3.05 1.23 3.63 3.06 1.24 3.75 3.33 1.25 4.00 3.34 1.26 4.12 3.61 1.27 4.37 3.60 1.28 4.61 3.83 1.30
46 2.45 2.45 0.94 2.73 2.63 0.95 2.82 2.82 0.96 3.01 2.87 0.97 3.10 3.10 0.97 3.29 3.09 0.98 3.47 3.29 0.99
¢
Model: ARXG18KHTAP
AFR
m
3
/h
1,050
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 4.17 3.74 0.41 4.65 3.76 0.42 4.80 4.09 0.42 5.12 4.10 0.43 5.28 4.43 0.43 5.60 4.41 0.43 5.91 4.70 0.44
-10 4.20 3.76 0.36 4.68 3.79 0.36 4.84 4.12 0.36 5.16 4.13 0.37 5.32 4.46 0.37 5.64 4.44 0.37 5.96 4.73 0.38
0 3.99 3.67 0.55 4.44 3.69 0.56 4.60 4.02 0.56 4.90 4.03 0.57 5.05 4.35 0.57 5.35 4.33 0.58 5.66 4.62 0.58
5 3.91 3.65 0.59 4.36 3.67 0.60 4.50 3.99 0.60 4.80 4.00 0.61 4.95 4.32 0.61 5.25 4.30 0.62 5.54 4.58 0.62
10 4.05 3.71 0.40 4.51 3.73 0.40 4.67 4.05 0.40 4.98 4.07 0.41 5.13 4.39 0.41 5.44 4.37 0.41 5.75 4.66 0.42
15 3.92 3.66 0.49 4.36 3.68 0.50 4.51 4.01 0.50 4.81 4.02 0.51 4.96 4.34 0.51 5.26 4.32 0.52 5.56 4.60 0.52
20 4.83 4.04 0.94 5.39 4.07 0.95 5.57 4.42 0.96 5.94 4.44 0.97 6.12 4.79 0.97 6.49 4.77 0.98 6.85 5.08 0.99
25 4.59 3.89 1.07 5.11 3.91 1.09 5.29 4.26 1.09 5.64 4.27 1.10 5.81 4.61 1.11 6.16 4.59 1.12 6.51 4.89 1.13
30 4.35 3.74 1.20 4.84 3.76 1.22 5.01 4.09 1.22 5.34 4.10 1.23 5.50 4.43 1.24 5.83 4.41 1.25 6.16 4.70 1.26
35 4.11 3.58 1.31 4.58 3.60 1.33 4.73 3.91 1.34 5.04 3.93 1.35 5.20 4.24 1.36 5.51 4.22 1.37 5.82 4.50 1.39
40 3.68 3.49 1.19 4.10 3.51 1.21 4.24 3.82 1.22 4.52 3.83 1.23 4.66 4.14 1.24 4.94 4.12 1.25 5.22 4.39 1.26
46 2.58 2.58 0.90 2.87 2.77 0.91 2.97 2.97 0.92 3.16 3.02 0.93 3.26 3.26 0.93 3.46 3.25 0.94 3.65 3.46 0.95
- 9 -
