Fujitsu AO G12KBTB Series Design & Technical Manual

1. Specifications
Type Inverter heat pump
Model name AOYG12KBTB AOYG14KBTB AOYG18KBTB AOYG22KBTB
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 4.8 5.8 7.1 8.2
Fan
Airflow rate
Cooling
m
3
/h
1,580 1,670 2,160 2,240
Heating 1,520 1,580 1,830 1,960
Type × Q'ty Propeller fan × 1
Motor output W 23 49
Sound pressure level *1
Cooling
dB (A)
47 49 50 51
Heating 47 49 50 51
Sound power level
Cooling
dB (A)
61 62 62 63
Heating 61 62 62 63
Heat exchanger type
Dimensions
(H × W × D)
mm
504 × 881 × 18.19
504 × 851 × 18.19
588 × 881 × 18.19
588 × 851 × 18.19
Fin pitch 1.3
Rows × Stages 2 × 24 2 × 28
Pipe type Copper tube
Fin type
Type (Material) Aluminum
Surface treatment PC fin
Compressor
Type × Q'ty DC Twin rotary × 1
Motor output W 810 900 1,060
Refrigerant
Type (Global warming potential) R32 (675)
Charge g 850 1,020 1,250
Refrigerant oil
Type FW68S RmM68AF
Amount
cm
3
350 400
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
542 × 799 × 290 632 × 799 × 290
Gross 602 × 940 × 375 692 × 940 × 375
Weight
Net
kg
33 36 38
Gross 37 40 42
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.70 (Ø 1/2)
Method Flare
Pre-charge length
m
15 20
Max. length 25 30
Max. height difference 20 25
Operation range
Cooling
°C
-15 to 46
Heating -15 to 24
Drain hose
Material PP
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
