Fujitsu AOU12RL2

4-2. Heating capacity
¢
Model: ASU9RL2
AFR CFM 436
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
15 11 8.17 0.86 7.97 0.88 7.78 0.89 7.59 0.91 7.39 0.93
23 19 9.24 0.90 9.02 0.92 8.80 0.94 8.58 0.96 8.36 0.98
32 28 10.32 0.95 10.07 0.97 9.83 0.99 9.58 1.01 9.34 1.03
41 37 12.19 1.01 11.90 1.03 11.61 1.05 11.32 1.07 11.03 1.09
47 43 12.62 1.00 12.32 1.02 12.02 1.04 11.72 1.06 11.42 1.08
50 47 13.65 1.06 13.33 1.08 13.00 1.10 12.68 1.13 12.35 1.15
59 50 14.20 1.07 13.86 1.09 13.53 1.12 13.19 1.14 12.85 1.16
68 59 12.72 1.01 12.41 1.03 12.11 1.05 11.81 1.07 11.50 1.09
75 65 16.08 1.11 15.69 1.13 15.31 1.15 14.93 1.18 14.55 1.20
AFR
m
3
/h
740
Indoor temperature
°CDB 15.6 18.3 21.1 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-9.4 -11.1 2.39 0.86 2.34 0.88 2.28 0.89 2.22 0.91 2.17 0.93
-5.0 -7.2 2.71 0.90 2.64 0.92 2.58 0.94 2.51 0.96 2.45 0.98
0.0 -2.2 3.02 0.95 2.95 0.97 2.88 0.99 2.81 1.01 2.74 1.03
5.0 2.8 3.57 1.01 3.49 1.03 3.40 1.05 3.32 1.07 3.23 1.09
8.3 6.1 3.70 1.00 3.61 1.02 3.52 1.04 3.44 1.06 3.35 1.08
10.0 8.3 4.00 1.06 3.91 1.08 3.81 1.10 3.72 1.13 3.62 1.15
15.0 10.0 4.16 1.07 4.06 1.09 3.96 1.12 3.87 1.14 3.77 1.16
20.0 15.0 3.73 1.01 3.64 1.03 3.55 1.05 3.46 1.07 3.37 1.09
23.9 18.0 4.71 1.11 4.60 1.13 4.49 1.15 4.38 1.18 4.26 1.20
¢
Model: ASU12RL2
AFR CFM 436
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
15 11 11.02 1.47 10.76 1.50 10.50 1.54 10.23 1.57 9.97 1.60
23 19 12.29 1.47 11.99 1.50 11.70 1.53 11.41 1.56 11.12 1.59
32 28 14.15 1.48 13.81 1.51 13.48 1.54 13.14 1.57 12.80 1.60
41 37 15.85 1.47 15.48 1.50 15.10 1.53 14.72 1.56 14.34 1.59
47 43 16.80 1.44 16.40 1.47 16.00 1.50 15.60 1.53 15.20 1.56
50 47 16.64 1.34 16.25 1.36 15.85 1.39 15.45 1.42 15.06 1.45
59 50 16.36 1.24 15.97 1.26 15.58 1.29 15.19 1.31 14.80 1.34
68 59 16.12 1.06 15.73 1.09 15.35 1.11 14.96 1.13 14.58 1.15
75 65 15.83 0.95 15.45 0.97 15.07 0.99 14.70 1.01 14.32 1.03
AFR
m
3
/h
740
Indoor temperature
°CDB 15.6 18.3 21.1 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-9.4 -11.1 3.23 1.47 3.15 1.50 3.08 1.54 3.00 1.57 2.92 1.60
-5.0 -7.2 3.60 1.47 3.52 1.50 3.43 1.53 3.34 1.56 3.26 1.59
0.0 -2.2 4.15 1.48 4.05 1.51 3.95 1.54 3.85 1.57 3.75 1.60
5.0 2.8 4.65 1.47 4.54 1.50 4.43 1.53 4.31 1.56 4.20 1.59
8.3 6.1 4.92 1.44 4.81 1.47 4.69 1.50 4.57 1.53 4.46 1.56
10.0 8.3 4.88 1.34 4.76 1.36 4.65 1.39 4.53 1.42 4.41 1.45
15.0 10.0 4.79 1.24 4.68 1.26 4.57 1.29 4.45 1.31 4.34 1.34
20.0 15.0 4.72 1.06 4.61 1.09 4.50 1.11 4.39 1.13 4.27 1.15
23.89 18.0 4.64 0.95 4.53 0.97 4.42 0.99 4.31 1.01 4.20 1.03
- 9 -
4-2. Heating capacity
4. Capacity table
WALL MOUNTED ASU9-12RL2 WALL MOUNTED ASU9-12RL2
