4. Refrigerant circuit
4-1. Models: AOU9RL2 and AOU12RL2
Strainer
Strainer
3-way
valve
2-way
valve
Muffler
4-w ay valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Compressor
Cooling
Heating
- 31 -
4-1. Models: AOU9RL2 and AOU12RL2
4. Refrigerant circuit
OUTDOOR UNIT
AOU9-12RL2
OUTDOOR UNIT
AOU9-12RL2
