Installation space requirement
Provide sufficient installation space for product safety.
CAUTION
Do not place any other electrical products or household belongings under the product. Condensa-
tion dripping from the product might get them wet, and may cause damage or malfunction to the
property.
Unit: in (mm)
3 (63) or more
3 (70) or more
Outline of unit
4 (100) or more
60 (1,500) or more
71 (1,800) or more
- 5 -
2-1. Models: ASU9RL2 and ASU12RL2
2. Dimensions
WALL MOUNTED
ASU9-12RL2
WALL MOUNTED
ASU9-12RL2
