Fujitsu AOU18RLXFZH Design & Technical Manual

- 163 -
OUTDOOR UNIT AOU18RLXFZH
 Indoor units: 9,000 Btu
 Indoor units: 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-15 -17 8.18 1.38 7.99 1.41 7.79 1.44 7.60 1.47 7.40 1.50
-5 -7 11.84 1.87 11.56 1.90 11.27 1.94 10.99 1.98 10.71 2.02
5 3 15.03 2.22 14.67 2.27 14.31 2.32 13.96 2.36 13.60 2.41
14 12 15.72 2.08 15.34 2.13 14.97 2.17 14.59 2.21 14.22 2.26
23 19 16.64 1.94 16.24 1.98 15.84 2.02 15.45 2.06 15.05 2.10
32 28 16.27 1.67 15.88 1.70 15.50 1.74 15.11 1.77 14.72 1.81
41 37 16.45 1.44 16.06 1.47 15.67 1.50 15.27 1.53 14.88 1.56
47 43 16.55 1.30 16.16 1.33 15.77 1.36 15.37 1.39 14.98 1.41
50 47 17.15 1.31 16.75 1.33 16.34 1.36 15.93 1.39 15.52 1.42
59 50 18.65 1.31 18.21 1.34 17.76 1.37 17.32 1.40 16.88 1.42
68 59 18.95 1.30 18.50 1.33 18.05 1.35 17.60 1.38 17.15 1.41
75 65 19.25 1.28 18.80 1.31 18.34 1.34 17.88 1.36 17.42 1.39
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-26.1 -27.0 2.40 1.38 2.34 1.41 2.28 1.44 2.23 1.47 2.17 1.50
-20.6 -21.7 3.47 1.87 3.39 1.90 3.30 1.94 3.22 1.98 3.14 2.02
-15.0 -16.1 4.40 2.22 4.30 2.27 4.20 2.32 4.09 2.36 3.99 2.41
-10.0 -11.1 4.61 2.08 4.50 2.13 4.39 2.17 4.28 2.21 4.17 2.26
-5.0 -7.2 4.88 1.94 4.76 1.98 4.64 2.02 4.53 2.06 4.41 2.10
0.0 -2.2 4.77 1.67 4.66 1.70 4.54 1.74 4.43 1.77 4.31 1.81
5.0 2.8 4.82 1.44 4.71 1.47 4.59 1.50 4.48 1.53 4.36 1.56
8.3 6.1 4.85 1.30 4.74 1.33 4.62 1.36 4.51 1.39 4.39 1.41
10.0 8.3 5.03 1.31 4.91 1.33 4.79 1.36 4.67 1.39 4.55 1.42
15.0 10.0 5.47 1.31 5.34 1.34 5.21 1.37 5.08 1.40 4.95 1.42
20.0 15.0 5.55 1.30 5.42 1.33 5.29 1.35 5.16 1.38 5.03 1.41
23.9 18.3 5.64 1.28 5.51 1.31 5.37 1.34 5.24 1.36 5.11 1.39
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-15 -17 9.35 1.72 9.13 1.75 8.91 1.79 8.68 1.83 8.46 1.86
-5 -7 13.53 2.32 13.21 2.37 12.88 2.42 12.56 2.46 12.24 2.51
5 3 17.18 2.76 16.77 2.82 16.36 2.88 15.95 2.94 15.54 3.00
14 12 17.96 2.59 17.53 2.64 17.11 2.70 16.68 2.75 16.25 2.80
23 19 19.01 2.41 18.56 2.46 18.11 2.51 17.65 2.56 17.20 2.61
32 28 18.60 2.07 18.15 2.12 17.71 2.16 17.27 2.20 16.82 2.25
41 37 18.80 1.79 18.35 1.83 17.90 1.87 17.46 1.90 17.01 1.94
47 43 18.92 1.62 18.47 1.65 18.02 1.69 17.57 1.72 17.12 1.76
50 47 19.60 1.62 19.14 1.66 18.67 1.69 18.20 1.73 17.74 1.76
59 50 21.32 1.63 20.81 1.67 20.30 1.70 19.79 1.74 19.29 1.77
68 59 21.66 1.62 21.15 1.65 20.63 1.68 20.11 1.72 19.60 1.75
75 65 22.00 1.60 21.48 1.63 20.96 1.66 20.43 1.70 19.91 1.73
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-26.1 -27.0 2.74 1.72 2.68 1.75 2.61 1.79 2.54 1.83 2.48 1.86
-20.6 -21.7 3.96 2.32 3.87 2.37 3.78 2.42 3.68 2.46 3.59 2.51
-15.0 -16.1 5.03 2.76 4.91 2.82 4.79 2.88 4.67 2.94 4.55 3.00
-10.0 -11.1 5.26 2.59 5.14 2.64 5.01 2.70 4.89 2.75 4.76 2.80
-5.0 -7.2 5.57 2.41 5.44 2.46 5.31 2.51 5.17 2.56 5.04 2.61
0.0 -2.2 5.45 2.07 5.32 2.12 5.19 2.16 5.06 2.20 4.93 2.25
5.0 2.8 5.51 1.79 5.38 1.83 5.25 1.87 5.12 1.90 4.98 1.94
8.3 6.1 5.54 1.62 5.41 1.65 5.28 1.69 5.15 1.72 5.02 1.76
10.0 8.3 5.75 1.62 5.61 1.66 5.47 1.69 5.34 1.73 5.20 1.76
15.0 10.0 6.25 1.63 6.10 1.67 5.95 1.70 5.80 1.74 5.65 1.77
20.0 15.0 6.35 1.62 6.20 1.65 6.05 1.68 5.89 1.72 5.74 1.75
23.9 18.3 6.45 1.60 6.30 1.63 6.14 1.66 5.99 1.70 5.83 1.73
