Fujitsu AOU36RLXB Technical Manual

-
(
01 - 10
)
-
WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

:ASU18RLB
AFR : Air flow rate (CFM)
TC : Total capacity (kBtu/h)
SHC : Sensible Heat capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
IP : Input Power (kW)
AFR 541
Indoor temperature
64°FDB 70°FDB 75°FDB 80°FDB 85°FDB 90°FDB
54°FWB 60°FWB 63°FWB 67°FWB 71°FWB 73°FWB
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
14 15.8 11.8 0.50 17.6 13.1 0.50 19.4 14.5 0.53 20.0 14.9 0.51 21.2 15.8 0.51 22.4 16.7 0.53
23 15.5 11.6 0.54 17.3 12.9 0.54 19.1 14.2 0.57 19.7 14.6 0.56 20.8 15.5 0.56 22.0 16.4 0.58
32 15.3 11.4 0.56 17.0 12.7 0.56 18.8 14.0 0.59 19.4 14.4 0.58 20.5 15.3 0.58 21.7 16.2 0.59
41 15.1 11.2 0.57 16.8 12.5 0.57 18.5 13.8 0.60 19.1 14.2 0.59 20.2 15.1 0.59 21.3 15.9 0.61
50 14.8 11.0 0.58 16.5 12.3 0.59 18.2 13.5 0.62 18.7 14.0 0.60 19.9 14.8 0.60 21.0 15.6 0.62
59 14.6 10.8 0.62 16.2 12.1 0.62 17.9 13.3 0.66 18.4 13.7 0.64 19.5 14.5 0.64 20.7 15.4 0.66
67 16.7 13.3 1.00 18.6 13.4 1.02 20.5 14.6 1.04 21.2 15.8 1.04 22.4 15.7 1.05 23.7 16.8 1.06
77 16.0 12.7 1.13 17.8 12.8 1.14 19.6 13.9 1.17 20.2 15.0 1.17 21.4 15.0 1.18 22.6 16.0 1.19
87 15.2 12.0 1.26 17.0 12.1 1.27 18.7 13.2 1.30 19.3 14.3 1.31 20.5 14.2 1.32 21.6 15.2 1.33
95 14.2 11.3 1.39 15.8 11.4 1.42 17.4 12.4 1.43 18.0 13.4 1.44 19.1 13.3 1.45 20.2 14.2 1.46
104 12.9 9.9 1.37 14.4 10.0 1.39 15.8 10.9 1.42 16.3 11.8 1.42 17.3 11.7 1.43 18.3 12.5 1.45
115 12.0 9.1 1.34 13.4 9.1 1.37 14.8 9.9 1.39 15.2 10.7 1.39 16.1 10.7 1.42 17.0 11.4 1.43
AFR 15.3
Indoor temperature
17.8°CDB 21.1°CDB 23.9°CDB 26.7°CDB 29.4°CDB 32.2°CDB
12.2°CWB 15.6°CWB 17.7°CWB 19.4°CWB 21.7°CWB 22.8°CWB
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 4.63 3.45 0.50 5.16 3.85 0.50 5.69 4.24 0.53 5.86 4.37 0.51 6.20 4.62 0.51 6.56 4.89 0.53
-5.0 4.56 3.39 0.54 5.08 3.78 0.54 5.60 4.16 0.57 5.77 4.29 0.56 6.11 4.54 0.56 6.46 4.80 0.58
0.0 4.49 3.34 0.56 5.00 3.72 0.56 5.51 4.10 0.59 5.68 4.23 0.58 6.01 4.48 0.58 6.36 4.74 0.59
5.0 4.41 3.29 0.57 4.92 3.67 0.57 5.42 4.04 0.60 5.59 4.16 0.59 5.92 4.41 0.59 6.25 4.66 0.61
10.0 4.34 3.23 0.58 4.84 3.60 0.59 5.33 3.97 0.62 5.49 4.09 0.60 5.82 4.34 0.60 6.15 4.58 0.62
15.0 4.27 3.18 0.62 4.76 3.54 0.62 5.24 3.90 0.66 5.40 4.02 0.64 5.73 4.26 0.64 6.05 4.50 0.66
19.4 4.90 3.91 1.00 5.46 3.93 1.02 6.02 4.28 1.04 6.21 4.63 1.04 6.58 4.60 1.05 6.95 4.91 1.06
25.0 4.68 3.72 1.13 5.21 3.75 1.14 5.75 4.08 1.17 5.92 4.40 1.17 6.27 4.39 1.18 6.63 4.68 1.19
30.6 4.47 3.52 1.26 4.98 3.55 1.27 5.49 3.87 1.30 5.66 4.18 1.31 5.99 4.17 1.32 6.34 4.44 1.33
35.0 4.17 3.31 1.39 4.64 3.34 1.42 5.11 3.64 1.43 5.28 3.93 1.44 5.59 3.91 1.45 5.91 4.17 1.46
40.0 3.78 2.92 1.37 4.21 2.93 1.39 4.64 3.20 1.42 4.78 3.45 1.42 5.07 3.44 1.43 5.35 3.66 1.45
46.1 3.52 2.66 1.34 3.92 2.67 1.37 4.32 2.92 1.39 4.45 3.14 1.39 4.73 3.13 1.42 4.99 3.34 1.43
