Fujitsu AOU36RLXB Technical Manual

-
(
01 - 14
)
-
WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
HEATING CAPACITY6-2.
MODEL

:ASU18RLB
AFR 541
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 16.2 1.98 15.8 2.01 15.4 2.18 14.6 2.14
14 12 17.3 1.87 16.9 1.90 16.5 2.13 15.6 2.02
23 19 18.1 1.81 17.7 1.84 17.2 2.05 16.3 1.96
32 28 18.2 1.81 17.8 1.85 17.3 1.95 16.5 1.96
41 37 19.9 1.92 19.4 1.95 19.0 2.00 18.0 2.08
47 43 21.0 1.98 20.5 2.01 20.0 2.06 19.0 2.14
50 47 23.2 2.01 22.7 2.04 22.1 2.09 21.0 2.17
59 50 24.0 2.05 23.4 2.09 22.9 2.10 21.8 2.22
AFR

: Air flow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 15.3
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16.1 4.73 1.98 4.64 2.01 4.51 2.18 4.29 2.14
-10.0 -11.1 5.08 1.87 4.95 1.90 4.83 2.13 4.59 2.02
-5.0 -7.2 5.30 1.81 5.17 1.84 5.03 2.05 4.78 1.96
0.0 -2.2 5.35 1.81 5.22 1.85 5.08 1.95 4.83 1.96
5.0 2.8 5.84 1.92 5.69 1.95 5.57 2.00 5.27 2.08
8.3 6.1 6.16 1.98 6.01 2.01 5.86 2.06 5.57 2.14
10.0 8.3 6.79 2.01 6.65 2.04 6.47 2.09 6.16 2.17
15.0 10.0 7.04 2.05 6.87 2.09 6.72 2.10 6.38 2.22
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
MODEL

:ASU24RLB
AFR 647
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 21.8 2.44 21.4 2.48 20.8 2.69 19.8 2.64
14 12 23.4 2.30 22.8 2.34 22.3 2.62 21.1 2.49
23 19 24.4 2.23 23.8 2.27 23.2 2.53 22.0 2.41
32 28 24.6 2.23 24.1 2.28 23.4 2.40 22.3 2.42
41 37 26.9 2.37 26.2 2.41 25.6 2.46 24.3 2.56
47 43 28.4 2.44 27.7 2.48 27.0 2.54 25.6 2.64
50 47 31.3 2.48 30.6 2.52 29.8 2.58 28.4 2.68
59 50 32.4 2.53 31.6 2.57 31.0 2.59 29.4 2.73
AFR

: Air flow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 18.3
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16.1 6.39 2.44 6.26 2.48 6.09 2.69 5.79 2.64
-10.0 -11.1 6.85 2.30 6.69 2.34 6.52 2.62 6.19 2.49
-5.0 -7.2 7.15 2.23 6.99 2.27 6.79 2.53 6.46 2.41
0.0 -2.2 7.22 2.23 7.05 2.28 6.85 2.40 6.52 2.42
5.0 2.8 7.88 2.37 7.68 2.41 7.52 2.46 7.12 2.56
8.3 6.1 8.31 2.44 8.11 2.48 7.91 2.54 7.52 2.64
10.0 8.3 9.17 2.48 8.97 2.52 8.74 2.58 8.31 2.68
15.0 10.0 9.50 2.53 9.27 2.57 9.07 2.59 8.61 2.73
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
