WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
Air conditioner filter features

Organic coating fin used
heat exchanger
Pre Filter
Antibacterial deodorizing
pre-filter with special
ceramic powder
Ion Deodorization Filter
Apple-catechin Filter
Apple-
catechin Filter
Long-life Ion
Deodorization Filter
Economy operation

Example : Cooling operation
Economy operation is energy saving, as ●
the set temperature of indoor unit is shifted
by 2°F and the maximum electric value of
the outdoor unit is suppressed.
Temp.
Economy operation
Shift
setting
temp
Control maxmum current
Nomal operation
Time
Set temperature
Blue fin heat exchanger (30, 36 Model)

Corrosion-resistance of the heat exchanger even in coastal areas has been improved by blue fin
treatment of the outdoor unit heat exchanger.
Blue fin heat exchanger
Cobalt Blue protection
Standard chromate protection
Aluminium base material
Hydrophilic coating
