Fujitsu AOU36RLXB Technical Manual

-
(
01 - 15
)
-
WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
MODEL

:ASU30RLXB
AFR 677
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 23.2 3.78 22.7 3.86 22.1 3.94 21.0 4.10
14 12 25.0 3.78 24.4 3.86 23.8 3.93 22.6 4.09
23 19 28.8 3.79 28.1 3.87 27.5 3.95 26.1 4.11
32 28 31.6 3.76 30.9 3.84 30.1 3.91 28.6 4.07
41 37 34.6 3.80 33.8 3.88 32.9 3.96 31.3 4.12
47 43 34.7 3.15 33.8 3.21 33.0 3.28 31.4 3.41
50 47 35.7 3.14 34.8 3.20 34.0 3.27 32.3 3.40
59 50 34.4 2.74 33.6 2.80 32.8 2.86 31.1 2.97
AFR

: Air flow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 19.2
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16.1 6.81 3.78 6.65 3.86 6.48 3.94 6.16 4.10
-10.0 -11.1 7.33 3.78 7.15 3.86 6.98 3.93 6.63 4.09
-5.0 -7.2 8.45 3.79 8.25 3.87 8.05 3.95 7.65 4.11
0.0 -2.2 9.27 3.76 9.05 3.84 8.83 3.91 8.38 4.07
5.0 2.8 10.14 3.80 9.90 3.88 9.66 3.96 9.17 4.12
8.3 6.1 10.16 3.15 9.91 3.21 9.70 3.28 9.19 3.41
10.0 8.3 10.46 3.14 10.21 3.20 9.96 3.27 9.47 3.40
15.0 10.0 10.09 2.74 9.85 2.80 9.61 2.86 9.13 2.97
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
MODEL

:ASU36RLXB
AFR 695
Indoor temperature
60°FDB 65°FDB 70°FDB 75°FDB
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
5 3 24.6 4.04 24.1 4.12 23.5 4.20 22.3 4.28
14 12 26.5 4.03 25.9 4.11 25.3 4.20 24.0 4.28
23 19 30.6 4.05 29.9 4.13 29.1 4.22 27.7 4.28
32 28 33.5 4.01 32.7 4.09 31.9 4.18 30.3 4.28
41 37 36.7 4.06 35.8 4.14 34.9 4.23 33.2 4.28
47 43 36.8 3.36 35.9 3.43 35.0 3.50 33.3 3.64
50 47 37.9 3.35 37.0 3.42 36.1 3.49 34.3 3.63
59 50 36.5 2.92 35.6 2.99 34.8 3.05 33.0 3.17
AFR

: Air flow rate (CFM)
TC : Total capacity (kBtu/h)
IP : Input Power (kW)
AFR 19.7
Indoor temperature
15.6°CDB 18.3°CDB 21.1°CDB 23.9°CDB
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-15.0 -16.1 7.22 4.04 7.05 4.12 6.88 4.20 6.53 4.28
-10.0 -11.1 7.77 4.03 7.59 4.11 7.40 4.20 7.03 4.28
-5.0 -7.2 8.96 4.05 8.75 4.13 8.54 4.22 8.11 4.28
0.0 -2.2 9.83 4.01 9.59 4.09 9.36 4.18 8.89 4.28
5.0 2.8 10.75 4.06 10.50 4.14 10.24 4.23 9.73 4.28
8.3 6.1 10.77 3.36 10.51 3.43 10.26 3.50 9.75 3.64
10.0 8.3 11.10 3.35 10.83 3.42 10.57 3.49 10.04 3.63
15.0 10.0 10.70 2.92 10.45 2.99 10.19 3.05 9.68 3.17
AFR : Air flow rate (m
3
/min)
TC : Total capacity (kW)
IP : Input Power (kW)
