01 - 17
)
-
WALL MOUNTED TYPE
ASU18-36RL
WALL MOUNTED TYPE ASU18-36RL
MODEL

: ASU24RLB
Conditions:
Fan speed : High
Operation mode : FAN
Voltage : 230V
2
1
0
1
2
(m)
(m)
TOP VIEW
Vertical air flow direction louver : Up
Horizontal airflow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
1
2
3
(m)
(m)
TOP VIEW
Vertical air flow direction louver : Up
Horizontal airflow direction louver : Right & Left
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical air flow direction louver : Down
Horizontal airflow direction louver : Center
Unit : ft/s (m/s)
012345678
3
2
1
0
(m)
(m)
SIDE VIEW
Vertical air flow direction louver : Up
Horizontal airflow direction louver : Center
Unit : ft/s (m/s)
012345678
(ft)
7142027
7
3
0
3
7
(ft)
(ft)
7142027
(ft)
7142027
(ft)
7142027
10
7
3
0
10
7
3
0
3
7
10
10
7
3
0
(ft)
(ft)
(ft)
7(2)
3(1)
2(0.5)
7(2)
3(1)
2(0.5)
2(0.5)
2(0.5)
3(1)
3(1)
7(2)
7(2)
7(2) 3(1)
2(0.5)
