Fujitsu AOU36RLXB Technical Manual

-
(
02 - 03
)
-
OUTDOOR UNIT AOU18-36RL OUTDOOR UNIT AOU18-36RL
MODEL

:AOU30RLXB, AOU36RLXB
Unit : in. (mm)
24 (600)
or more
4 (100)
or more
24 (600) or more
12 (300)
or more
4 (100)
or more
12 (300) or more
(Service space)
10 (250)
or more
10 (250)
or more
12 (300)
or more
When there are obstacles at
the back or front sides.
When there are obstacles at
the back, side(s), and top.
When there are obstacles at the
back, side with the installation of
more than one unit.
Top view
Front view
Side view
Bottom view
3-1/16 (77)
35-7/16 (900)
32-11/16 (830)
17-5/16 (440)
13/16 (21)
15-3/4 (400)
13 (330)
7-11/16 (196)
5-13/16 (147)
6-11/16 (170)
14-9/16 (370)
25-9/16 (650)
Air Flow
1-1/4
(31)
1/2
(12)
3-7/8 (99)
3/8 (9)
INSTALLATION PLACE


Fujitsu AOU36RLXB Specifications

General

Brand	Fujitsu
Model	AOU36RLXB
Category	Air Conditioner
Language	English
