8-3. Current release control
The rotation number of compressor is controlled so that the outdoor unit input current does not ex-
ceeds current limit value set according to the outdoor temperature.
The rotation number of compressor returns according to the operation mode, when the current be-
comes lower than the release value.
¢ Models: AOYG07KGCA, AOYG09KGCA, and AOYG12KGCA
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
50°C ≤ Ta 4.0 A 3.5 A
46°C ≤ Ta < 50°C 4.0 A 3.5 A
40°C ≤ Ta < 46°C 5.0 A 4.5 A
12°C ≤ Ta < 40°C 6.0 A 5.5 A
2°C ≤ Ta < 12°C 6.0 A 5.5 A
Ta < 2°C 6.0 A 5.5 A
Heating
17°C ≤ Ta 5.5 A 5.0 A
12°C ≤ Ta < 17°C 7.0 A 6.5 A
5°C ≤ Ta < 12°C 7.5 A 7.0 A
Ta < 5°C 8.5 A 8.0 A
¢ Model: AOYG14KGCA
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
50°C ≤ Ta 4.5 A 4.0 A
46°C ≤ Ta < 50°C 4.5 A 4.0 A
40°C ≤ Ta < 46°C 6.0 A 5.5 A
12°C ≤ Ta < 40°C 8.5 A 8.0 A
2°C ≤ Ta < 12°C 8.5 A 8.0 A
Ta < 2°C 8.5 A 8.0 A
Heating
17°C ≤ Ta 7.0 A 6.5 A
12°C ≤ Ta < 17°C 9.0 A 8.5 A
5°C ≤ Ta < 12°C 10.0 A 9.5 A
Ta < 5°C 10.0 A 9.5 A
8-4. Cooling pressure over-rise protection
→hen the outdoor unit heat exchanger temperature reaches trigger condition below, the compressor
is stopped and trouble display is performed.
Trigger condition 65°C
8-3. Current release control - (04-31) - 8. Various protections
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS

Fujitsu AOYG09KGCA Specifications

General

Type	Air conditioner outdoor unit
Multi-split	-
Product color	White
Inverter technology	Yes
Refrigerating medium	R32
Dehumidifying capacity	1.3 l/h
Air conditioner functions	Circulation, Cooling, Dehumidifying, Fan, Heating, Ventilating
Refrigerating medium weight	750 g
Cooling capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	4.5
Heating energy efficiency (COP, W/W)	5
Seasonal efficiency rating (cooling) (SEER)	8.52
Seasonal efficiency rating (heating) (SCOP)	5.11
Current (cooling)	6.5 A
Current (heating)	9 A
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	2.5 kWh
Hourly energy consumption (heating)	2.8 kWh
Design load (heating) (Warmer heating season)	2.4 kW
Design load (heating) (Average heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Warmer heating season)	658 kWh
Annual energy consumption (heating) (Average heating season)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	799 mm
Outdoor unit height	542 mm
Outdoor unit weight	30000 g
Outdoor units quantity	1
Outdoor unit noise level	63 dB
Cooling airflow (outdoor unit)	1610 m³/h
