Fujitsu AOYG14KMCC Design & Technical Manual

1. Specifications
Type Inverter heat pump
Model name AOYG07KMCC AOYG09KMCC AOYG12KMCC AOYG14KMCC
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 3.0 3.4 5.1 6.8
Fan
Airflow rate
Cooling
m
3
/h
1,650 1,650 1,700 1,680
Heating 1,450 1,450 1,470 1,580
Type × Q'ty Propeller fan × 1
Motor output W 23
Sound pressure level *1
Cooling
dB (A)
46 50
Heating 46 50
Sound power level
Cooling
dB (A)
61 65
Heating 61 62 65 66
Heat exchanger type
Dimensions
(H × W × D)
mm
504 × 650 × 18.2 504 × 630 × 36.4 504 × 881 × 36.4
Fin pitch 1.3
Rows × Stages 1 × 24 2 × 24
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance
Compressor
Type × Q'ty DC rotary × 1
Motor output W 550 900
Refrigerant
Type (Global warming potential) R32 (675)
Charge g 600 700 850
Refrigerant oil
Type RB74AF RB68A
Amount
cm
3
240 340
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
541 × 663 × 290 542 × 799 × 290
Gross 602 × 804 × 375 602 × 940 × 375
Weight
Net
kg
22 24 31
Gross 25 27 35
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
Drain hose
Material PP
Tip diameter mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 40 -
1. Specifications
OUTDOOR UNIT AOYG07-14KMCC OUTDOOR UNIT
AOYG07-14KMCC
