Fujitsu AOYG14KMCC Design & Technical Manual

2. Dimensions
2-1. Models: ASYG07KMCC, ASYG09KMCC, ASYG12KMCC,
and ASYG14KMCC
Unit: mm
(834)
Outline of indoor unit
327
273273 54
(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
- 4 -
2-1. Models: ASYG07KMCC, ASYG09KMCC, ASYG12KMCC, and ASYG14KMCC 2. Dimensions
WALL MOUNTED ASYG07-14KMCC WALL MOUNTED ASYG07-14KMCC
