Fujitsu AOYG14KMCC - Dimensions; Models: AOYG07 KMCC, AOYG09 KMCC, and AOYG12 KMCC

2. Dimensions
2-1. Models: AOYG07KMCC, AOYG09KMCC, and
AOYG12KMCC
Unit: mm
Airflow
106450
19 663 68 16
33 30
290
353
330
Pitch of bolts for installation
4-
M1 0 hole
Bottom view Side view (Valve part)
Top view
Side view
Side view
Front view
Pitch of bolts for installation
353
541
20
184
120
37
170
331
Drain port Ø42
- 41 -
2-1. Models: AOYG07KMCC, AOYG09KMCC, and AOYG12KMCC 2. Dimensions
OUTDOOR UNIT AOYG07-14KMCC OUTDOOR UNIT
AOYG07-14KMCC
