Fujitsu AOYG14KMCC - Additional Charge Calculation; Models: AOYG07 KMCC and AOYG09 KMCC; Model: AOYG12 KMCC; Model: AOYG14 KMCC

7. Additional charge calculation
7-1. Models: AOYG07KMCC and AOYG09KMCC
Refrigerant type R32
Refrigerant amount g 600
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge g 0 100
7-2. Model: AOYG12KMCC
Refrigerant type R32
Refrigerant amount g 700
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge g 0 100
7-3. Model: AOYG14KMCC
Refrigerant type R32
Refrigerant amount g 850
¢ Refrigerant charge
Total pipe length m 15 or less 20 (Max.)
20 g/m
Additional charge g 0 100
- 51 -
7-1. Models: AOYG07KMCC and AOYG09KMCC 7. Additional charge calculation
OUTDOOR UNIT AOYG07-14KMCC OUTDOOR UNIT AOYG07-14KMCC
