Fujitsu AOYG18KBTA3 Design & Technical Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
19
-15.0
-16.0 6.1 2.85 5.9 2.91 5.8 2.97 5.7 3.02 5.5 3.08
-10.0 -11.0 6.9 3.02 6.7 3.08 6.5 3.14 6.4 3.20 6.2 3.27
-5.0 -7.0 7.3 2.75 7.2 2.80 7.0 2.86 6.8 2.92 6.6 2.97
0.0 -2.0 8.0 2.45 7.8 2.50 7.6 2.55 7.4 2.60 7.2 2.66
5.0 3.0 8.0 1.90 7.8 1.94 7.6 1.98 7.4 2.02 7.2 2.06
7.0 6.0 8.0 1.67 7.8 1.71 7.6 1.74 7.4 1.78 7.2 1.81
10.0 8.0 8.0 1.57 7.8 1.60 7.6 1.64 7.4 1.67 7.2 1.70
15.0 10.0 8.0 1.42 7.8 1.45 7.6 1.48 7.4 1.51 7.2 1.54
20.0 15.0 8.0 1.20 7.8 1.23 7.6 1.25 7.4 1.28 7.2 1.30
24.0 18.0 8.0 1.08 7.8 1.10 7.6 1.12 7.4 1.14 7.2 1.17
18
-15.0
-16.0 5.8 2.71 5.6 2.76 5.5 2.82 5.4 2.88 5.2 2.93
-10.0 -11.0 6.5 2.87 6.3 2.93 6.2 2.99 6.0 3.05 5.9 3.11
-5.0 -7.0 6.9 2.61 6.8 2.67 6.6 2.72 6.5 2.77 6.3 2.83
0.0 -2.0 7.6 2.33 7.4 2.38 7.2 2.43 7.0 2.48 6.8 2.53
5.0 3.0 7.6 1.81 7.4 1.85 7.2 1.89 7.0 1.92 6.8 1.96
7.0 6.0 7.6 1.59 7.4 1.62 7.2 1.66 7.0 1.69 6.8 1.72
10.0 8.0 7.6 1.49 7.4 1.52 7.2 1.56 7.0 1.59 6.8 1.62
15.0 10.0 7.6 1.35 7.4 1.38 7.2 1.41 7.0 1.44 6.8 1.47
20.0 15.0 7.6 1.14 7.4 1.17 7.2 1.19 7.0 1.21 6.8 1.24
24.0 18.0 7.6 1.02 7.4 1.05 7.2 1.07 7.0 1.09 6.8 1.11
16
-15.0
-16.0 5.1 2.43 5.0 2.48 4.9 2.53 4.8 2.58 4.6 2.63
-10.0 -11.0 5.8 2.57 5.6 2.63 5.5 2.68 5.4 2.73 5.2 2.79
-5.0 -7.0 6.2 2.34 6.0 2.39 5.9 2.44 5.7 2.49 5.6 2.54
0.0 -2.0 6.7 2.09 6.6 2.13 6.4 2.18 6.2 2.22 6.1 2.27
5.0 3.0 6.7 1.62 6.6 1.66 6.4 1.69 6.2 1.73 6.1 1.76
7.0 6.0 6.7 1.43 6.6 1.46 6.4 1.49 6.2 1.51 6.1 1.54
10.0 8.0 6.7 1.34 6.6 1.37 6.4 1.40 6.2 1.42 6.1 1.45
15.0 10.0 6.7 1.21 6.6 1.24 6.4 1.26 6.2 1.29 6.1 1.31
20.0 15.0 6.7 1.02 6.6 1.05 6.4 1.07 6.2 1.09 6.1 1.11
24.0 18.0 6.7 0.92 6.6 0.94 6.4 0.96 6.2 0.98 6.1 1.00
14
-15.0
-16.0 4.5 2.19 4.4 2.24 4.3 2.28 4.2 2.33 4.1 2.37
-10.0 -11.0 5.1 2.32 4.9 2.37 4.8 2.42 4.7 2.46 4.6 2.51
-5.0 -7.0 5.4 2.11 5.3 2.16 5.1 2.20 5.0 2.24 4.9 2.29
0.0 -2.0 5.9 1.89 5.7 1.92 5.6 1.96 5.5 2.00 5.3 2.04
5.0 3.0 5.9 1.46 5.7 1.49 5.6 1.53 5.5 1.56 5.3 1.59
7.0 6.0 5.9 1.29 5.7 1.31 5.6 1.34 5.5 1.37 5.3 1.39
10.0 8.0 5.9 1.21 5.7 1.23 5.6 1.26 5.5 1.28 5.3 1.31
15.0 10.0 5.9 1.09 5.7 1.12 5.6 1.14 5.5 1.16 5.3 1.19
20.0 15.0 5.9 0.92 5.7 0.94 5.6 0.96 5.5 0.98 5.3 1.00
24.0 18.0 5.9 0.83 5.7 0.85 5.6 0.86 5.5 0.88 5.3 0.90
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 14,000 Btu/h up to 30,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 393 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
