Fujitsu AOYG18KBTA3 Design & Technical Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.23 2.18 2.13 2.07 2.02
-10.0 -11.0 2.53 2.47 2.41 2.35 2.29
-5.0 -7.0 2.70 2.64 2.58 2.51 2.45
0.0 -2.0 2.94 2.87 2.80 2.73 2.66
5.0 3.0 2.94 2.87 2.80 2.73 2.66
7.0 6.0 2.94 2.87 2.80 2.73 2.66
10.0 8.0 2.94 2.87 2.80 2.73 2.66
15.0 10.0 2.94 2.87 2.80 2.73 2.66
20.0 15.0 2.94 2.87 2.80 2.73 2.66
24.0 18.0 2.94 2.87 2.80 2.73 2.66
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.87 2.80 2.74 2.67 2.60
-10.0 -11.0 3.25 3.17 3.10 3.02 2.94
-5.0 -7.0 3.48 3.39 3.31 3.23 3.15
0.0 -2.0 3.78 3.69 3.60 3.51 3.42
5.0 3.0 3.78 3.69 3.60 3.51 3.42
7.0 6.0 3.78 3.69 3.60 3.51 3.42
10.0 8.0 3.78 3.69 3.60 3.51 3.42
15.0 10.0 3.78 3.69 3.60 3.51 3.42
20.0 15.0 3.78 3.69 3.60 3.51 3.42
24.0 18.0 3.78 3.69 3.60 3.51 3.42
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.83 3.74 3.65 3.56 3.47
-10.0 -11.0 4.33 4.23 4.13 4.02 3.92
-5.0 -7.0 4.64 4.53 4.42 4.31 4.20
0.0 -2.0 5.04 4.92 4.80 4.68 4.56
5.0 3.0 5.04 4.92 4.80 4.68 4.56
7.0 6.0 5.04 4.92 4.80 4.68 4.56
10.0 8.0 5.04 4.92 4.80 4.68 4.56
15.0 10.0 5.04 4.92 4.80 4.68 4.56
20.0 15.0 5.04 4.92 4.80 4.68 4.56
24.0 18.0 5.04 4.92 4.80 4.68 4.56
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.25 4.15 4.05 3.95 3.85
-10.0 -11.0 4.81 4.70 4.58 4.47 4.35
-5.0 -7.0 5.15 5.03 4.90 4.78 4.66
0.0 -2.0 5.60 5.46 5.33 5.20 5.06
5.0 3.0 5.60 5.46 5.33 5.20 5.06
7.0 6.0 5.60 5.46 5.33 5.20 5.06
10.0 8.0 5.60 5.46 5.33 5.20 5.06
15.0 10.0 5.60 5.46 5.33 5.20 5.06
20.0 15.0 5.60 5.46 5.33 5.20 5.06
24.0 18.0 5.60 5.46 5.33 5.20 5.06
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 394 -
