Fujitsu ARHG24LMLA User Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model: ARHG24LMLA
AFR
m
3
/h
1,100
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 5.62 4.62 0.60 6.26 4.65 0.61 6.47 5.05 0.62 6.90 5.07 0.62 7.11 5.48 0.62 7.54 5.45 0.63 7.97 5.81 0.64
0 5.53 4.58 0.65 6.16 4.60 0.66 6.37 5.00 0.66 6.79 5.02 0.67 7.00 5.42 0.67 7.42 5.40 0.68 7.83 5.75 0.68
5 5.34 4.49 0.79 5.94 4.51 0.80 6.15 4.91 0.80 6.55 4.92 0.81 6.75 5.32 0.82 7.16 5.29 0.82 7.57 5.64 0.83
10 5.13 4.38 0.92 5.71 4.40 0.93 5.90 4.79 0.94 6.29 4.80 0.95 6.49 5.19 0.95 6.88 5.17 0.96 7.27 5.50 0.97
15 5.25 4.44 0.76 5.85 4.47 0.78 6.05 4.86 0.78 6.45 4.87 0.79 6.65 5.26 0.79 7.05 5.24 0.80 7.45 5.58 0.81
20 6.11 4.65 1.49 6.81 4.68 1.51 7.04 5.09 1.52 7.51 5.10 1.53 7.74 5.51 1.54 8.20 5.49 1.56 8.67 5.85 1.57
25 5.87 4.53 1.70 6.54 4.56 1.72 6.76 4.96 1.73 7.21 4.97 1.75 7.43 5.37 1.76 7.88 5.35 1.78 8.32 5.70 1.80
30 5.62 4.41 1.92 6.26 4.44 1.95 6.47 4.83 1.96 6.90 4.84 1.98 7.11 5.23 1.99 7.54 5.21 2.01 7.96 5.55 2.03
35 5.37 4.30 2.13 5.98 4.32 2.17 6.19 4.70 2.18 6.60 4.71 2.20 6.80 5.09 2.21 7.21 5.07 2.23 7.62 5.40 2.25
40 5.13 4.38 2.05 5.71 4.41 2.08 5.91 4.79 2.09 6.30 4.80 2.11 6.49 5.19 2.12 6.88 5.17 2.14 7.27 5.51 2.16
46 3.66 3.66 1.56 4.08 3.70 1.58 4.22 4.02 1.59 4.50 4.03 1.60 4.64 4.36 1.61 4.91 4.34 1.63 5.19 4.62 1.64
4-2. Heating capacity
¢
Model: ARHG24LMLA
AFR
m
3
/h
1,100
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.27 2.75 6.12 2.81 5.97 2.87 5.82 2.93 5.67 2.98
-10 -11 7.10 2.97 6.93 3.04 6.76 3.10 6.60 3.16 6.43 3.22
-5 -7 7.94 3.12 7.75 3.18 7.56 3.25 7.37 3.31 7.18 3.38
0 -2 8.80 3.05 8.59 3.12 8.38 3.18 8.17 3.25 7.96 3.31
5 3 9.33 2.77 9.11 2.83 8.89 2.89 8.67 2.95 8.45 3.01
7 6 9.56 2.66 9.33 2.71 9.10 2.77 8.87 2.83 8.65 2.88
10 8 9.85 2.66 9.62 2.72 9.38 2.78 9.15 2.83 8.91 2.89
15 10 9.03 2.13 8.82 2.17 8.60 2.22 8.39 2.26 8.17 2.31
20 15 8.29 1.65 8.09 1.69 7.90 1.72 7.70 1.76 7.50 1.79
24 18 8.58 1.65 8.38 1.68 8.17 1.72 7.97 1.75 7.77 1.79
- 7 -
DUCT TYPE ARHG24LMLA

Fujitsu ARHG24LMLA Specifications

General

Brand	Fujitsu
Model	ARHG24LMLA
Category	Air Conditioner
Language	English
