1. Specifications
Type Inverter heat pump
Model name AOHG24LBCB
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 9.9
Fan
Airflow rate
Cooling
m
3
/h
2,850
Heating 2,700
Type × Q'ty Propeller × 1
Motor output W 49
Sound pressure level *1
Cooling
dB (A)
53
Heating 54
Sound power level
Cooling
dB (A)
66
Heating 66
Heat exchanger type
Dimensions
(H × W × D)
mm
672 × 881 × 18.19
672 × 851 × 18.19
Fin pitch 1.3
Rows × Stages 2 × 32
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance
Compressor
Type × Q'ty Twin rotary × 1
Motor output W 1,200
Refrigerant
Type (Global warming potential) R410A
Charge g 1,500
Refrigerant oil
Type RB68
Amount
cm
3
550
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
716 × 820 × 315
Gross 776 × 961 × 450
Weight
Net
kg
42
Gross 47
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 15.88 (Ø 5/8)
Method Flare
Pre-charge length
m
15
Max. length 30
Max. height difference 20
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
Drain hose
Material PP+LLDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 38 -
OUTDOOR UNIT AOHG24LBCB
