1. Specifications
Type Inverter heat pump
Model name ARHG24LMLA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 6.8
Btu/h 23,200
Min.—Max.
kW 0.9—8.0
Btu/h 3,100—27,300
Heating
Rated
kW 8.00
Btu/h 27,300
Min.—Max.
kW 0.90—9.10
Btu/h 3,100—31,000
Input power
Cooling
Rated
kW
2.21
Max. 2.85
Heating
Rated 2.26
Max. 3.19
Current
Cooling
Rated A
9.7
Heating 9.9
Power factor
Cooling
%
99.1
Heating 99.3
EER Cooling
kW/kW
3.08
COP Heating 3.54
Moisture removal L/h (pints/h) 2.5 (4.4)
Maximum operating current *1
Cooling
A
14.7
Heating 15.7
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,100
MED 910
LOW 750
QUIET 580
Heating
HIGH 1,100
MED 910
LOW 750
QUIET 580
Type × Q'ty Sirocco × 2
Motor output W 106
Static pressure range Pa 30 to 150
Sound pressure level *2
Cooling
HIGH
dB (A)
31
MED 29
LOW 27
QUIET 25
Heating
HIGH 31
MED 29
LOW 27
QUIET 25
Sound power level
Cooling
HIGH dB (A)
60
Heating 62
Heat exchanger type
Dimensions (H × W × D)
mm
294 × 1,000 × 39.9
Fin pitch 1.40
Rows × Stages 3 × 14
Pipe type Copper
Fin type Aluminum
Enclosure
Material Steel
Color —
Dimensions
(H × W × D)
Net
mm
270 × 1,135 × 700
Gross 300 × 1,320 × 790
Weight
Net
kg
38
Gross 44
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4 in.)
Gas Ø 15.88 (Ø 5/8 in.)
Method Flare
Drain hose
Material Steel
Size mm Ø35.7 (I.D.), Ø38.1 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wired [Wireless (option)]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Standard static pressure: 35 Pa.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current:
– The maximum value when operated within the operation range.
– The total current of indoor unit and outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 2 -
DUCT TYPE ARHG24LMLA
