Model: AOYG24KBTB
Unit: mm
Side viewSide view Front view
Top view
16 315
20 18
Airflow
600
109
353
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
82019 68
716
20
Drain port Ø42
37
410
Bottom view Side view (Valve part)
119
184
194
2-2. Outdoor unit - (01-15) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
