Item no. Part no. Part name Service part
1 9384321015 Intake grille B sub assy ♦
2 9383344008 Grille hinge ♦
3 9384321008 Intake grille A sub assy ♦
4 9383342004 Air filter A ♦
5 9383342011 Air filter B ♦
6 9384307002 Casing U assy ♦
7 9357921006 Bearing B assy ♦
8 9384110008 Sirocco fan assy ♦
9 9383443008 Rubber (Vibration proof) ♦
10 9384110015 Sirocco fan assy ♦
11 9603816001 Brushless DC motor ♦
12 9384236005 Motor mount assy ♦
13 9384311009 Casing B assy ♦
14 9352173011 Cap (Power) ♦
15 9383406003 Side panel L ♦
16 9384308016 Top panel cover assy (3-fan) ♦
17 9384144010 Flap assy (3-fan) ♦
18 9384324009 Hose sub assy ♦
19 9383384004 L and R louver ♦
20 9383385001 Base (Louver) ♦
21 9900896027 Terminal (5P) ♦
22
9710995996 Main PCB (for 24 model) ♦
9711524003 Main PCB (for 30 model) ♦
23 9384312006 Box (Gear) sub assy ♦
24 9900960049 Thermistor (Room) ♦
25 9710661006 Power supply PCB ♦
26 9710019005 2-way remote PCB ♦
27 9306489045 Terminal (3P) ♦
28 9384320001 Side panel R sub assy ♦
29 9900892029 Thermistor (Pipe) ♦
30
9384287014 Evaporator total assy (for 24 model) ♦
9384287038 Evaporator total assy (for 30 model) ♦
31 9384364012 Drain pan total assy (3-fan) ♦
32 9358746004 Drain cap ♦
33 9384241016 Front panel (3-fan) assy ♦
2-2. Models: ABYG24KRTA and ABYG30KRTA - (02-5) - 2. Indoor unit parts list
