Item no. Part no. Part name Service part

1 9384321015 Intake grille B sub assy ♦

2 9383344008 Grille hinge (2 pcs.) ♦

3 9383342011 Air filter B ♦

4 9384307002 Casing U assy ♦

5 9384110015 Sirocco fan assy ♦

6 9383443008 Rubber (Vibration proof) ♦

7 9603817008 Brushless DC motor ♦

8 9384236005 Motor mount assy ♦

9 9384311009 Casing B assy ♦

10 9352173011 Cap (Power) ♦

11 9383406003 Side panel L ♦

12 9384308023 Top panel cover assy (2-fan) ♦

13 9384144027 Flap assy (2-fan) ♦

14 9384324009 Hose sub assy ♦

15 9383384004 L and R louver ♦

16 9383385001 Base (Louver) ♦

17 9900896027 Terminal (5P) ♦

9710995972 Main PCB (for 18 model) ♦

9710995989 Main PCB (for 22 model) ♦

19 9384312006 Box (Gear) sub assy ♦

20 9900960049 Thermistor (Room) ♦

21 9710661006 Power supply PCB ♦

22 9710019005 2-way remote PCB ♦

23 9306489045 Terminal (3P) ♦

24 9384320001 Side panel R sub assy ♦

25 9900892029 Thermistor (Pipe) ♦

26 9384287021 Evaporator total assy ♦

27 9384364029 Drain pan total assy (2-fan) ♦

28 9358746004 Drain cap ♦

29 9384241023 Front panel (2-fan) assy ♦

2-1. Models: ABYG18KRTA and ABYG22KRTA - (02-3) - 2. Indoor unit parts list
