2. Dimensions
2-1. Models: AOTG09KMTC and AOTG12KMTC
Unit: mm
Top view
580 109
330
353
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
799 68
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
180
Side view
Side view
Front view
29016
184
120
- 47 -
2-1. Models: AOTG09KMTC and AOTG12KMTC 2. Dimensions
OUTDOOR UNIT
AOTG09-12KMTC
OUTDOOR UNIT
AOTG09-12KMTC
