Fujitsu ASTG09KMTC - 2. Dimensions

2. Dimensions
2-1. Models: ASTG09KMTC and ASTG12KMTC
Unit: mm
(834)
Outline of indoor unit
327
273273 54
(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
- 3 -
2-1. Models: ASTG09KMTC and ASTG12KMTC 2. Dimensions
WALL MOUNTED ASTG09-12KMTC WALL MOUNTED ASTG09-12KMTC
