Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 13.66 1.67 13.23 1.72 12.78 1.76 12.34 1.81 12.07 1.84
14 12 15.58 1.78 15.09 1.84 14.58 1.89 14.07 1.94 13.76 1.97
23 19 16.55 1.76 16.03 1.81 15.48 1.86 14.94 1.91 14.61 1.94
32 28 17.62 1.69 17.07 1.74 16.49 1.79 15.91 1.84 15.56 1.87
41 37 19.81 1.59 19.19 1.63 18.54 1.68 17.89 1.73 17.50 1.76
47 43 21.13 1.61 20.46 1.65 19.77 1.70 19.08 1.75 18.66 1.77
50 47 21.29 1.62 20.62 1.67 19.92 1.72 19.22 1.77 18.80 1.80
59 50 22.14 1.71 21.44 1.76 20.72 1.81 19.99 1.86 19.55 1.89
68 59 21.08 1.33 20.41 1.37 19.72 1.40 19.03 1.44 18.61 1.47
75 65 20.42 1.16 19.78 1.20 19.11 1.23 18.44 1.26 18.03 1.29
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.00 1.67 3.88 1.72 3.75 1.76 3.62 1.81 3.54 1.84
-10.0 -11.1 4.57 1.78 4.42 1.84 4.27 1.89 4.12 1.94 4.03 1.97
-5.0 -7.2 4.85 1.76 4.70 1.81 4.54 1.86 4.38 1.91 4.28 1.94
0.0 -2.2 5.17 1.69 5.00 1.74 4.83 1.79 4.66 1.84 4.56 1.87
5.0 2.8 5.81 1.59 5.62 1.63 5.43 1.68 5.24 1.73 5.13 1.76
8.3 6.1 6.19 1.61 6.00 1.65 5.79 1.70 5.59 1.75 5.47 1.77
10.0 8.3 6.24 1.62 6.04 1.67 5.84 1.72 5.63 1.77 5.51 1.80
15.0 10.0 6.49 1.71 6.28 1.76 6.07 1.81 5.86 1.86 5.73 1.89
20.0 15.0 6.18 1.33 5.98 1.37 5.78 1.40 5.58 1.44 5.46 1.47
23.9 18.3 5.99 1.16 5.80 1.20 5.60 1.23 5.40 1.26 5.29 1.29
 Indoor units: 18,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.93 2.37 16.40 2.44 15.84 2.51 15.29 2.58 14.95 2.63
14 12 19.26 2.47 18.65 2.54 18.02 2.61 17.39 2.68 17.01 2.73
23 19 20.62 2.55 19.96 2.62 19.29 2.69 18.61 2.77 18.20 2.82
32 28 22.38 2.40 21.67 2.47 20.94 2.54 20.21 2.61 19.76 2.65
41 37 25.35 2.37 24.55 2.44 23.72 2.51 22.89 2.58 22.38 2.63
47 43 27.03 2.40 26.18 2.47 25.29 2.54 24.41 2.61 23.87 2.65
50 47 27.23 2.44 26.37 2.51 25.48 2.58 24.59 2.65 24.05 2.69
59 50 27.50 2.37 26.63 2.44 25.73 2.51 24.83 2.58 24.29 2.63
68 59 26.96 1.99 26.11 2.05 25.23 2.11 24.35 2.17 23.81 2.20
75 65 24.27 1.42 23.50 1.47 22.71 1.51 21.91 1.55 21.43 1.58
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.96 2.37 4.81 2.44 4.64 2.51 4.48 2.58 4.38 2.63
-10.0 -11.1 5.64 2.47 5.47 2.54 5.28 2.61 5.10 2.68 4.98 2.73
-5.0 -7.2 6.04 2.55 5.85 2.62 5.65 2.69 5.46 2.77 5.34 2.82
0.0 -2.2 6.56 2.40 6.35 2.47 6.14 2.54 5.92 2.61 5.79 2.65
5.0 2.8 7.43 2.37 7.19 2.44 6.95 2.51 6.71 2.58 6.56 2.63
8.3 6.1 7.92 2.40 7.67 2.47 7.41 2.54 7.15 2.61 7.00 2.65
10.0 8.3 7.98 2.44 7.73 2.51 7.47 2.58 7.21 2.65 7.05 2.69
15.0 10.0 8.06 2.37 7.81 2.44 7.54 2.51 7.28 2.58 7.12 2.63
20.0 15.0 7.90 1.99 7.65 2.05 7.39 2.11 7.14 2.17 6.98 2.20
23.9 18.3 7.11 1.42 6.89 1.47 6.65 1.51 6.42 1.55 6.28 1.58
- 228 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
