Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 7,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 13.26 1.82 12.84 1.88 12.41 1.93 11.97 1.99 11.71 2.02
14 12 15.69 1.94 15.20 1.99 14.68 2.05 14.17 2.11 13.86 2.14
23 19 17.23 1.90 16.69 1.95 16.13 2.01 15.56 2.07 15.22 2.10
32 28 19.10 1.84 18.49 1.90 17.87 1.95 17.24 2.01 16.86 2.04
41 37 20.74 1.79 20.09 1.84 19.41 1.89 18.73 1.95 18.32 1.98
47 43 22.12 1.86 21.42 1.91 20.70 1.97 19.98 2.03 19.54 2.06
50 47 23.28 1.88 22.55 1.93 21.78 1.99 21.02 2.05 20.56 2.08
59 50 25.64 1.90 24.83 1.95 23.99 2.01 23.15 2.07 22.64 2.10
68 59 23.32 1.66 22.59 1.71 21.82 1.76 21.06 1.80 20.59 1.83
75 65 20.19 1.11 19.55 1.14 18.89 1.17 18.23 1.20 17.83 1.22
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 3.89 1.82 3.76 1.88 3.64 1.93 3.51 1.99 3.43 2.02
-10.0 -11.1 4.60 1.94 4.45 1.99 4.30 2.05 4.15 2.11 4.06 2.14
-5.0 -7.2 5.05 1.90 4.89 1.95 4.73 2.01 4.56 2.07 4.46 2.10
0.0 -2.2 5.60 1.84 5.42 1.90 5.24 1.95 5.05 2.01 4.94 2.04
5.0 2.8 6.08 1.79 5.89 1.84 5.69 1.89 5.49 1.95 5.37 1.98
8.3 6.1 6.48 1.86 6.28 1.91 6.07 1.97 5.85 2.03 5.73 2.06
10.0 8.3 6.82 1.88 6.61 1.93 6.38 1.99 6.16 2.05 6.03 2.08
15.0 10.0 7.51 1.90 7.28 1.95 7.03 2.01 6.78 2.07 6.64 2.10
20.0 15.0 6.84 1.66 6.62 1.71 6.40 1.76 6.17 1.80 6.04 1.83
23.9 18.3 5.92 1.11 5.73 1.14 5.54 1.17 5.34 1.20 5.22 1.22
 Indoor units: 7,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 14.81 2.38 14.34 2.45 13.86 2.52 13.37 2.59 13.08 2.63
14 12 17.49 2.53 16.94 2.60 16.36 2.67 15.79 2.75 15.44 2.79
23 19 19.23 2.48 18.62 2.55 17.99 2.62 17.36 2.69 16.98 2.74
32 28 21.50 2.40 20.82 2.47 20.12 2.54 19.41 2.62 18.98 2.66
41 37 23.75 2.33 23.00 2.40 22.22 2.47 21.44 2.54 20.97 2.58
47 43 25.33 2.43 24.53 2.50 23.70 2.57 22.87 2.64 22.37 2.69
50 47 26.58 2.42 25.74 2.49 24.87 2.57 24.00 2.64 23.47 2.68
59 50 26.75 2.23 25.91 2.29 25.03 2.36 24.15 2.42 23.62 2.46
68 59 24.68 1.87 23.90 1.93 23.09 1.98 22.29 2.04 21.80 2.07
75 65 23.39 1.44 22.65 1.48 21.88 1.53 21.12 1.57 20.65 1.60
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.34 2.38 4.20 2.45 4.06 2.52 3.92 2.59 3.83 2.63
-10.0 -11.1 5.13 2.53 4.96 2.60 4.80 2.67 4.63 2.75 4.53 2.79
-5.0 -7.2 5.63 2.48 5.46 2.55 5.27 2.62 5.09 2.69 4.98 2.74
0.0 -2.2 6.30 2.40 6.10 2.47 5.90 2.54 5.69 2.62 5.56 2.66
5.0 2.8 6.96 2.33 6.74 2.40 6.51 2.47 6.28 2.54 6.15 2.58
8.3 6.1 7.42 2.43 7.19 2.50 6.95 2.57 6.70 2.64 6.56 2.69
10.0 8.3 7.79 2.42 7.54 2.49 7.29 2.57 7.03 2.64 6.88 2.68
15.0 10.0 7.84 2.23 7.59 2.29 7.34 2.36 7.08 2.42 6.92 2.46
20.0 15.0 7.23 1.87 7.01 1.93 6.77 1.98 6.53 2.04 6.39 2.07
23.9 18.3 6.85 1.44 6.64 1.48 6.41 1.53 6.19 1.57 6.05 1.60
- 229 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
