Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.31 2.51 15.79 2.58 15.26 2.66 14.72 2.73 14.40 2.78
14 12 18.98 2.67 18.38 2.74 17.76 2.82 17.14 2.90 16.76 2.95
23 19 21.00 2.61 20.34 2.69 19.65 2.76 18.96 2.84 18.54 2.89
32 28 23.63 2.54 22.88 2.61 22.11 2.68 21.33 2.76 20.86 2.80
41 37 25.65 2.46 24.84 2.53 24.00 2.60 23.16 2.68 22.65 2.72
47 43 27.36 2.56 26.50 2.63 25.60 2.71 24.70 2.79 24.16 2.83
50 47 28.64 2.56 27.73 2.63 26.79 2.70 25.86 2.78 25.29 2.83
59 50 28.71 2.25 27.81 2.31 26.87 2.38 25.92 2.45 25.35 2.49
68 59 27.93 1.89 27.05 1.94 26.13 2.00 25.22 2.06 24.66 2.09
75 65 25.23 1.65 24.44 1.70 23.61 1.74 22.79 1.79 22.28 1.82
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.78 2.51 4.63 2.58 4.47 2.66 4.32 2.73 4.22 2.78
-10.0 -11.1 5.56 2.67 5.39 2.74 5.21 2.82 5.02 2.90 4.91 2.95
-5.0 -7.2 6.15 2.61 5.96 2.69 5.76 2.76 5.56 2.84 5.43 2.89
0.0 -2.2 6.92 2.54 6.71 2.61 6.48 2.68 6.25 2.76 6.11 2.80
5.0 2.8 7.52 2.46 7.28 2.53 7.03 2.60 6.79 2.68 6.64 2.72
8.3 6.1 8.02 2.56 7.77 2.63 7.50 2.71 7.24 2.79 7.08 2.83
10.0 8.3 8.39 2.56 8.13 2.63 7.85 2.70 7.58 2.78 7.41 2.83
15.0 10.0 8.42 2.25 8.15 2.31 7.87 2.38 7.60 2.45 7.43 2.49
20.0 15.0 8.19 1.89 7.93 1.94 7.66 2.00 7.39 2.06 7.23 2.09
23.9 18.3 7.40 1.65 7.16 1.70 6.92 1.74 6.68 1.79 6.53 1.82
 Indoor units: 7,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.48 2.52 15.96 2.59 15.42 2.67 14.88 2.74 14.55 2.79
14 12 19.34 2.52 18.73 2.59 18.09 2.67 17.46 2.74 17.08 2.79
23 19 21.88 2.52 21.19 2.59 20.48 2.67 19.76 2.74 19.32 2.79
32 28 24.61 2.47 23.83 2.54 23.02 2.61 22.22 2.69 21.73 2.73
41 37 27.56 2.54 26.69 2.61 25.78 2.69 24.88 2.76 24.33 2.81
47 43 29.39 2.66 28.46 2.73 27.50 2.81 26.54 2.89 25.95 2.94
50 47 30.42 2.23 29.46 2.30 28.46 2.36 27.47 2.43 26.86 2.47
59 50 30.14 2.10 29.19 2.16 28.20 2.23 27.21 2.29 26.61 2.33
68 59 28.66 1.77 27.76 1.82 26.82 1.87 25.88 1.92 25.31 1.96
75 65 27.07 1.69 26.21 1.74 25.33 1.79 24.44 1.84 23.90 1.87
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.83 2.52 4.68 2.59 4.52 2.67 4.36 2.74 4.26 2.79
-10.0 -11.1 5.67 2.52 5.49 2.59 5.30 2.67 5.12 2.74 5.00 2.79
-5.0 -7.2 6.41 2.52 6.21 2.59 6.00 2.67 5.79 2.74 5.66 2.79
0.0 -2.2 7.21 2.47 6.98 2.54 6.75 2.61 6.51 2.69 6.37 2.73
5.0 2.8 8.08 2.54 7.82 2.61 7.56 2.69 7.29 2.76 7.13 2.81
8.3 6.1 8.61 2.66 8.34 2.73 8.06 2.81 7.78 2.89 7.61 2.94
10.0 8.3 8.92 2.23 8.63 2.30 8.34 2.36 8.05 2.43 7.87 2.47
15.0 10.0 8.83 2.10 8.55 2.16 8.26 2.23 7.98 2.29 7.80 2.33
20.0 15.0 8.40 1.77 8.14 1.82 7.86 1.87 7.59 1.92 7.42 1.96
23.9 18.3 7.93 1.69 7.68 1.74 7.42 1.79 7.16 1.84 7.01 1.87
- 230 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
