Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 7,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 17.47 2.33 16.92 2.40 16.35 2.47 15.78 2.54 15.43 2.58
14 12 20.33 2.45 19.69 2.52 19.02 2.59 18.36 2.67 17.95 2.71
23 19 23.03 2.54 22.30 2.61 21.55 2.69 20.80 2.76 20.34 2.81
32 28 26.37 2.71 25.54 2.79 24.67 2.87 23.81 2.95 23.28 3.00
41 37 29.86 2.71 28.92 2.79 27.94 2.87 26.96 2.95 26.37 3.00
47 43 31.85 2.77 30.84 2.85 29.80 2.93 28.76 3.00 28.12 3.00
50 47 33.04 2.71 32.00 2.79 30.91 2.87 29.83 2.95 29.17 3.00
59 50 34.63 2.67 33.53 2.75 32.40 2.83 31.27 2.91 30.58 2.96
68 59 31.77 2.03 30.77 2.09 29.72 2.15 28.68 2.21 28.05 2.24
75 65 29.61 1.70 28.68 1.75 27.71 1.80 26.74 1.85 26.15 1.88
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.12 2.33 4.96 2.40 4.79 2.47 4.62 2.54 4.52 2.58
-10.0 -11.1 5.96 2.45 5.77 2.52 5.58 2.59 5.38 2.67 5.26 2.71
-5.0 -7.2 6.75 2.54 6.54 2.61 6.32 2.69 6.10 2.76 5.96 2.81
0.0 -2.2 7.73 2.71 7.48 2.79 7.23 2.87 6.98 2.95 6.82 3.00
5.0 2.8 8.75 2.71 8.48 2.79 8.19 2.87 7.90 2.95 7.73 3.00
8.3 6.1 9.33 2.77 9.04 2.85 8.73 2.93 8.43 3.00 8.24 3.00
10.0 8.3 9.68 2.71 9.38 2.79 9.06 2.87 8.74 2.95 8.55 3.00
15.0 10.0 10.15 2.67 9.83 2.75 9.50 2.83 9.16 2.91 8.96 2.96
20.0 15.0 9.31 2.03 9.02 2.09 8.71 2.15 8.41 2.21 8.22 2.24
23.9 18.3 8.68 1.70 8.40 1.75 8.12 1.80 7.84 1.85 7.66 1.88
 Indoor units: 7,000 Btu + 7,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 17.59 2.28 17.03 2.34 16.46 2.41 15.88 2.48 15.53 2.52
14 12 20.47 2.39 19.82 2.46 19.15 2.53 18.48 2.60 18.07 2.65
23 19 23.19 2.48 22.45 2.55 21.70 2.63 20.94 2.70 20.47 2.74
32 28 26.54 2.68 25.71 2.76 24.84 2.84 23.97 2.92 23.44 2.97
41 37 30.06 2.68 29.11 2.76 28.13 2.84 27.14 2.92 26.55 2.97
47 43 32.06 2.70 31.05 2.78 30.00 2.86 28.95 2.94 28.31 2.99
50 47 33.26 2.68 32.21 2.76 31.12 2.84 30.03 2.92 29.37 2.97
59 50 34.86 2.60 33.76 2.67 32.62 2.75 31.48 2.82 30.78 2.87
68 59 31.98 1.98 30.97 2.04 29.92 2.10 28.88 2.15 28.24 2.19
75 65 32.45 1.77 31.43 1.82 30.36 1.87 29.30 1.93 28.66 1.96
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.16 2.28 4.99 2.34 4.82 2.41 4.65 2.48 4.55 2.52
-10.0 -11.1 6.00 2.39 5.81 2.46 5.61 2.53 5.42 2.60 5.30 2.65
-5.0 -7.2 6.80 2.48 6.58 2.55 6.36 2.63 6.14 2.70 6.00 2.74
0.0 -2.2 7.78 2.68 7.53 2.76 7.28 2.84 7.02 2.92 6.87 2.97
5.0 2.8 8.81 2.68 8.53 2.76 8.24 2.84 7.96 2.92 7.78 2.97
8.3 6.1 9.40 2.70 9.10 2.78 8.79 2.86 8.48 2.94 8.30 2.99
10.0 8.3 9.75 2.68 9.44 2.76 9.12 2.84 8.80 2.92 8.61 2.97
15.0 10.0 10.22 2.60 9.89 2.67 9.56 2.75 9.23 2.82 9.02 2.87
20.0 15.0 9.37 1.98 9.08 2.04 8.77 2.10 8.46 2.15 8.28 2.19
23.9 18.3 9.51 1.77 9.21 1.82 8.90 1.87 8.59 1.93 8.40 1.96
- 235 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
