Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 17.59 2.33 17.03 2.40 16.46 2.47 15.88 2.54 15.53 2.58
14 12 20.47 2.45 19.82 2.52 19.15 2.59 18.48 2.67 18.07 2.71
23 19 23.19 2.54 22.45 2.61 21.70 2.69 20.94 2.76 20.47 2.81
32 28 26.54 2.71 25.71 2.79 24.84 2.87 23.97 2.95 23.44 3.00
41 37 30.06 2.71 29.11 2.79 28.13 2.87 27.14 2.95 26.55 3.00
47 43 32.06 2.77 31.05 2.85 30.00 2.93 28.95 3.00 28.31 3.00
50 47 33.26 2.71 32.21 2.79 31.12 2.87 30.03 2.95 29.37 3.00
59 50 34.86 2.67 33.76 2.75 32.62 2.83 31.48 2.91 30.78 2.96
68 59 31.98 2.03 30.97 2.09 29.92 2.15 28.88 2.21 28.24 2.24
75 65 32.09 1.77 31.08 1.82 30.03 1.87 28.98 1.92 28.34 1.96
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.16 2.33 4.99 2.40 4.82 2.47 4.65 2.54 4.55 2.58
-10.0 -11.1 6.00 2.45 5.81 2.52 5.61 2.59 5.42 2.67 5.30 2.71
-5.0 -7.2 6.80 2.54 6.58 2.61 6.36 2.69 6.14 2.76 6.00 2.81
0.0 -2.2 7.78 2.71 7.53 2.79 7.28 2.87 7.02 2.95 6.87 3.00
5.0 2.8 8.81 2.71 8.53 2.79 8.24 2.87 7.96 2.95 7.78 3.00
8.3 6.1 9.40 2.77 9.10 2.85 8.79 2.93 8.48 3.00 8.30 3.00
10.0 8.3 9.75 2.71 9.44 2.79 9.12 2.87 8.80 2.95 8.61 3.00
15.0 10.0 10.22 2.67 9.89 2.75 9.56 2.83 9.23 2.91 9.02 2.96
20.0 15.0 9.37 2.03 9.08 2.09 8.77 2.15 8.46 2.21 8.28 2.24
23.9 18.3 9.41 1.77 9.11 1.82 8.80 1.87 8.49 1.92 8.31 1.96
 Indoor units: 9,000 Btu + 9,000 Btu + 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 17.59 2.33 17.03 2.40 16.46 2.47 15.88 2.54 15.53 2.58
14 12 20.47 2.45 19.82 2.52 19.15 2.59 18.48 2.67 18.07 2.71
23 19 23.19 2.54 22.45 2.61 21.70 2.69 20.94 2.76 20.47 2.81
32 28 26.54 2.71 25.71 2.79 24.84 2.87 23.97 2.95 23.44 3.00
41 37 30.06 2.71 29.11 2.79 28.13 2.87 27.14 2.95 26.55 3.00
47 43 32.06 2.77 31.05 2.85 30.00 2.93 28.95 3.00 28.31 3.00
50 47 33.26 2.71 32.21 2.79 31.12 2.87 30.03 2.95 29.37 3.00
59 50 34.86 2.67 33.76 2.75 32.62 2.83 31.48 2.91 30.78 2.96
68 59 31.98 2.03 30.97 2.09 29.92 2.15 28.88 2.21 28.24 2.24
75 65 32.09 1.78 31.07 1.83 30.02 1.88 28.97 1.93 28.33 1.96
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.16 2.33 4.99 2.40 4.82 2.47 4.65 2.54 4.55 2.58
-10.0 -11.1 6.00 2.45 5.81 2.52 5.61 2.59 5.42 2.67 5.30 2.71
-5.0 -7.2 6.80 2.54 6.58 2.61 6.36 2.69 6.14 2.76 6.00 2.81
0.0 -2.2 7.78 2.71 7.53 2.79 7.28 2.87 7.02 2.95 6.87 3.00
5.0 2.8 8.81 2.71 8.53 2.79 8.24 2.87 7.96 2.95 7.78 3.00
8.3 6.1 9.40 2.77 9.10 2.85 8.79 2.93 8.48 3.00 8.30 3.00
10.0 8.3 9.75 2.71 9.44 2.79 9.12 2.87 8.80 2.95 8.61 3.00
15.0 10.0 10.22 2.67 9.89 2.75 9.56 2.83 9.23 2.91 9.02 2.96
20.0 15.0 9.37 2.03 9.08 2.09 8.77 2.15 8.46 2.21 8.28 2.24
23.9 18.3 9.40 1.78 9.11 1.83 8.80 1.88 8.49 1.93 8.30 1.96
- 236 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
