Fujitsu ASU18RLF Design & Technical Manual

2) Ducted
Combination of indoor unit
Rated capacity for each indoor unit
(kBtu/h)
Maximum capacity for each indoor
unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
Room 1 Room 2 Room 3 Room 4 Total Room 1 Room 2 Room 3 Room 4 Room 1 Room 2 Room 3 Room 4 Min. Rated Max. Min. Rated Max.
18 18 - - 36*1 16.70 16.70 - - 18.00 18.00 - - 11.00 33.40 36.00 0.94 3.89 4.36
7 7 18 - 32 7.00 7.00 18.00 - 7.90 7.90 19.60 - 11.00 32.00 35.40 0.98 3.72 4.28
7 7 24 - 38 6.50 6.50 22.20 - 6.80 6.80 23.40 - 11.00 35.20 37.00 0.98 4.10 4.48
7 9 12 - 28 7.00 9.00 12.00 - 8.00 10.20 13.50 - 11.00 28.00 31.70 0.98 3.27 3.85
7 9 18 - 34 6.90 8.80 17.80 - 7.50 9.80 19.10 - 11.00 33.50 36.40 0.98 3.90 4.41
7 12 12 - 31 7.00 12.00 12.00 - 8.00 13.50 13.50 - 11.00 31.00 35.00 0.98 3.61 4.24
7 12 18 - 37 6.70 11.40 17.10 - 7.00 12.00 18.00 - 11.00 35.20 37.00 0.98 4.10 4.48
9 9 9 - 27 9.00 9.00 9.00 - 10.20 10.20 10.20 - 11.00 27.00 30.60 0.98 3.14 3.70
9 9 12 - 30 9.00 9.00 12.00 - 10.20 10.20 13.50 - 11.00 30.00 33.90 0.98 3.49 4.10
9 9 18 - 36 8.80 8.80 17.60 - 9.20 9.20 18.60 - 11.00 35.20 37.00 0.98 4.10 4.48
9 12 12 - 33 8.80 11.80 11.80 - 9.90 13.10 13.10 - 11.00 32.40 36.10 0.98 3.77 4.37
9 12 18 - 39 8.20 10.80 16.20 - 8.50 11.40 17.10 - 11.00 35.20 37.00 0.98 4.10 4.48
12 12 12 - 36 11.70 11.70 11.80 - 12.30 12.30 12.30 - 11.00 35.20 36.90 0.98 4.10 4.47
7 7 7 7 28 7.00 7.00 7.00 7.00 8.00 8.00 8.00 8.00 11.00 28.00 32.00 1.17 3.10 3.64
7 7 7 9 30 7.00 7.00 7.00 9.00 8.00 8.00 8.00 10.20 11.00 30.00 34.20 1.17 3.32 3.90
7 7 7 12 33 6.90 6.90 6.90 11.80 7.70 7.70 7.70 13.00 11.00 32.50 36.10 1.17 3.60 4.16
7 7 7 18 39 6.30 6.30 6.30 16.30 6.80 6.80 6.80 17.60 11.00 35.20 38.00 1.17 3.90 4.38
7 7 9 9 32 7.00 7.00 9.00 9.00 7.80 7.80 10.00 10.00 11.00 32.00 35.60 1.17 3.55 4.03
7 7 9 12 35 6.90 6.90 8.90 11.80 7.50 7.50 9.70 12.90 11.00 34.50 37.60 1.17 3.82 4.33
7 7 12 12 38 6.50 6.50 11.10 11.10 7.00 7.00 12.00 12.00 11.00 35.20 38.00 1.17 3.90 4.38
7 9 9 9 34 6.90 8.90 8.90 8.90 7.70 9.90 9.90 9.90 11.00 33.60 37.40 1.17 3.72 4.31
7 9 9 12 37 6.70 8.60 8.60 11.30 7.20 9.20 9.20 12.40 11.00 35.20 38.00 1.17 3.90 4.38
9 9 9 9 36 8.80 8.80 8.80 8.80 9.50 9.50 9.50 9.50 11.00 35.20 38.00 1.17 3.90 4.38
9 9 9 12 39 8.12 8.12 8.12 10.84 8.77 8.77 8.77 11.69 11.00 35.20 38.00 1.17 3.90 4.38
NOTES:
•
*
1
: Optional kit K9FZ1818 (UTP-MU36A2) shall be necessary for the dual zone system “18
+ 18”.
•
*
2
: Wall mounted 18 type cannot be connected in this combination.
• Specifications are based on the following conditions.
– Power source of specifications: 230 V
– 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 15: 14,000 Btu/h, 18: 18,000 Btu/h, 24:
24,000 Btu/h
– 3 or more indoor units should be connected. (Only the combinations of the “18 + 18” can be
connected by using the optional kit K9FZ1818 (UTP-MU36A2).)
– Cooling: Indoor temperature of 80 °FDB (26.7 °CDB)/67 °FWB (19.4 °CWB), and outdoor
temperature of 95 °FDB (35 °CDB)/75 °FWB (23.9 °CWB).
– Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit—Indoor unit]
– The total ability of connected indoor units is from 27,000 Btu up to 39,000 Btu.
– Non-Ducted system combinations input are based on wall mount models. The input of combi-
nations including cassette models may be a little higher.
– Ducted system combinations capacities are based on slim duct units excepting 7,000-Btu
models. 7,000 Btu models are based on wall mount models.
- 256 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1
