Fujitsu ASU18RLF Design & Technical Manual

¢ Model: AOU36RLXFZ1

Heating
1) Non-ducted
Combination of indoor unit
Rated capacity for each indoor unit
(kBtu/h)
Maximum capacity for each indoor
unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
Room 1 Room 2 Room 3 Room 4 Total Room 1 Room 2 Room 3 Room 4 Room 1 Room 2 Room 3 Room 4 Min. Rated Max. Min. Rated Max.
18 18 - -
36*
1
17.30 17.30 - - 20.00 20.00 - - 11.00 34.60 40.00 1.02 2.99 3.70
7 7 15 - 29 7.20 7.20 15.50 - 8.80 8.80 18.50 - 11.00 29.90 36.10 0.87 2.57 3.34
7 7 18 - 32 7.20 7.20 18.60 - 8.70 8.70 21.70 - 11.00 33.00 39.10 0.87 2.86 3.62
7 7 24 - 38 6.70 6.70 23.00 - 7.50 7.50 26.00 - 11.00 36.40 41.00 0.87 3.15 3.79
7 9 12 - 28 7.20 9.30 12.40 - 8.80 11.30 14.90 - 11.00 28.90 35.00 0.87 2.50 3.24
7 9 15 - 31 7.20 9.30 15.50 - 8.80 11.30 18.50 - 11.00 32.00 38.60 0.87 2.77 3.57
7 9 18 - 34 7.10 9.10 18.40 - 8.30 10.80 21.10 - 11.00 34.60 40.20 0.87 2.99 3.72
7 12 12 - 31 7.20 12.40 12.40 - 8.80 14.90 14.90 - 11.00 32.00 38.60 0.87 2.77 3.57
7 12 15 - 34 7.10 12.20 15.30 - 8.20 13.90 17.70 - 11.00 34.60 39.80 0.87 2.99 3.68
7 12 18 - 37 6.90 11.80 17.70 - 7.70 13.30 20.00 - 11.00 36.40 41.00 0.87 3.15 3.79
9 9 9 - 27 9.30 9.30 9.30 - 11.30 11.30 11.30 - 11.00 27.90 33.90 0.87 2.41 3.14
9 9 12 - 30 9.30 9.30 12.40 - 11.30 11.30 14.90 - 11.00 31.00 37.50 0.87 2.68 3.47
9 9 15 - 33 9.10 9.10 15.30 - 10.90 10.90 18.00 - 11.00 33.50 39.80 0.87 2.90 3.68
9 9 18 - 36 9.10 9.10 18.20 - 10.20 10.20 20.60 - 11.00 36.40 41.00 0.87 3.15 3.79
9 12 12 - 33 9.10 12.20 12.20 - 10.90 14.50 14.50 - 11.00 33.50 39.90 0.87 2.90 3.69
9 12 15 - 36 9.20 12.10 15.10 - 10.30 13.60 17.00 - 11.00 36.40 40.90 0.87 3.15 3.78
9 12 18 - 39 8.50 11.20 16.70 - 9.40 12.60 19.00 - 11.00 36.40 41.00 0.97 3.15 3.79
12 12 12 - 36 12.10 12.10 12.20 - 13.60 13.60 13.60 - 11.00 36.40 40.80 0.87 3.15 3.77
12 12 15 - 39 11.20 11.20 14.00 - 12.60 12.60 15.80 - 11.00 36.40 41.00 0.87 3.15 3.79
7 7 7 7 28 7.20 7.20 7.20 7.20 8.80 8.80 8.80 8.80 11.00 28.80 35.20 0.87 2.37 3.07
7 7 7 9 30 7.20 7.20 7.20 9.30 8.80 8.80 8.80 11.30 11.00 30.90 37.70 0.87 2.55 3.29
7 7 7 12 33 7.10 7.10 7.10 12.20 8.50 8.50 8.50 14.40 11.00 33.50 39.90 0.87 2.76 3.52
7 7 7 15 36 7.10 7.10 7.10 15.00 8.30 8.30 8.30 17.10 11.00 36.30 42.00 0.87 2.99 3.70
7 7 7
18*
2
39 6.50 6.50 6.50 16.90 7.50 7.50 7.50 19.50 11.00 36.40 42.00 0.87 3.00 3.70
7 7 9 9 32 7.20 7.20 9.30 9.30 8.60 8.60 11.10 11.10 11.00 33.00 39.40 0.87 2.72 3.44
7 7 9 12 35 7.10 7.10 9.20 12.20 8.30 8.30 10.70 14.30 11.00 35.60 41.60 0.87 2.93 3.66
7 7 9 15 38 6.70 6.70 8.70 14.30 7.70 7.70 10.00 16.60 11.00 36.40 42.00 0.87 3.00 3.70
7 7 12 12 38 6.70 6.70 11.50 11.50 7.70 7.70 13.30 13.30 11.00 36.40 42.00 0.87 3.00 3.70
7 9 9 9 34 7.10 9.20 9.20 9.20 8.50 10.90 10.90 10.90 11.00 34.70 41.20 0.87 2.86 3.63
7 9 9 12 37 6.90 8.90 8.90 11.70 8.00 10.20 10.20 13.60 11.00 36.40 42.00 0.87 3.00 3.70
9 9 9 9 36 9.10 9.10 9.10 9.10 10.50 10.50 10.50 10.50 11.00 36.40 42.00 0.87 3.00 3.70
9 9 9 12 39 8.40 8.40 8.40 11.20 9.69 9.69 9.69 12.93 11.00 36.40 42.00 0.87 3.00 3.70
- 257 -
6-1. Combinations 6. Capacity table
