Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 14.59 1.92 14.24 1.96 13.90 2.00 13.55 2.04 13.20 2.08
14 12 17.76 1.95 17.34 1.99 16.91 2.03 16.49 2.07 16.07 2.11
23 19 20.50 1.98 20.01 2.02 19.52 2.06 19.03 2.10 18.54 2.14
32 28 21.80 1.86 21.28 1.90 20.76 1.94 20.24 1.98 19.72 2.02
41 37 22.85 1.84 22.30 1.88 21.76 1.92 21.21 1.96 20.67 2.00
47 43 24.12 1.94 23.54 1.98 22.97 2.02 22.40 2.06 21.82 2.10
50 47 24.51 1.93 23.93 1.97 23.35 2.01 22.76 2.05 22.18 2.09
59 50 25.69 1.91 25.08 1.95 24.47 1.99 23.86 2.03 23.25 2.07
68 59 26.12 1.65 25.50 1.68 24.88 1.72 24.26 1.75 23.63 1.79
75 65 27.58 1.64 26.92 1.68 26.26 1.71 25.61 1.75 24.95 1.78
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.28 1.92 4.17 1.96 4.07 2.00 3.97 2.04 3.87 2.08
-10.0 -11.1 5.20 1.95 5.08 1.99 4.96 2.03 4.83 2.07 4.71 2.11
-5.0 -7.2 6.01 1.98 5.86 2.02 5.72 2.06 5.58 2.10 5.44 2.14
0.0 -2.2 6.39 1.86 6.24 1.90 6.08 1.94 5.93 1.98 5.78 2.02
5.0 2.8 6.70 1.84 6.54 1.88 6.38 1.92 6.22 1.96 6.06 2.00
8.3 6.1 7.07 1.94 6.90 1.98 6.73 2.02 6.56 2.06 6.40 2.10
10.0 8.3 7.18 1.93 7.01 1.97 6.84 2.01 6.67 2.05 6.50 2.09
15.0 10.0 7.53 1.91 7.35 1.95 7.17 1.99 6.99 2.03 6.81 2.07
20.0 15.0 7.66 1.65 7.47 1.68 7.29 1.72 7.11 1.75 6.93 1.79
23.9 18.3 8.08 1.64 7.89 1.68 7.70 1.71 7.51 1.75 7.31 1.78
 Indoor units: 18,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 16.07 2.44 15.68 2.50 15.30 2.55 14.92 2.60 14.54 2.65
14 12 19.55 2.48 19.09 2.53 18.62 2.58 18.16 2.63 17.69 2.69
23 19 22.57 2.52 22.03 2.57 21.49 2.62 20.96 2.67 20.42 2.72
32 28 24.00 2.37 23.43 2.42 22.86 2.47 22.29 2.52 21.71 2.57
41 37 25.16 2.35 24.56 2.39 23.96 2.44 23.36 2.49 22.76 2.54
47 43 26.56 2.47 25.93 2.52 25.29 2.57 24.66 2.62 24.03 2.67
50 47 26.99 2.46 26.35 2.51 25.71 2.56 25.06 2.61 24.42 2.66
59 50 28.29 2.43 27.62 2.49 26.95 2.54 26.27 2.59 25.60 2.64
68 59 28.76 2.10 28.08 2.14 27.39 2.19 26.71 2.23 26.02 2.27
75 65 30.37 2.09 29.64 2.13 28.92 2.18 28.20 2.22 27.47 2.26
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 4.71 2.44 4.60 2.50 4.48 2.55 4.37 2.60 4.26 2.65
-10.0 -11.1 5.73 2.48 5.59 2.53 5.46 2.58 5.32 2.63 5.19 2.69
-5.0 -7.2 6.61 2.52 6.46 2.57 6.30 2.62 6.14 2.67 5.98 2.72
0.0 -2.2 7.03 2.37 6.87 2.42 6.70 2.47 6.53 2.52 6.36 2.57
5.0 2.8 7.37 2.35 7.20 2.39 7.02 2.44 6.85 2.49 6.67 2.54
8.3 6.1 7.78 2.47 7.60 2.52 7.41 2.57 7.23 2.62 7.04 2.67
10.0 8.3 7.91 2.46 7.72 2.51 7.53 2.56 7.35 2.61 7.16 2.66
15.0 10.0 8.29 2.43 8.09 2.49 7.90 2.54 7.70 2.59 7.50 2.64
20.0 15.0 8.43 2.10 8.23 2.14 8.03 2.19 7.83 2.23 7.63 2.27
23.9 18.3 8.90 2.09 8.69 2.13 8.48 2.18 8.26 2.22 8.05 2.26
- 281 -
6-3. Heating capacity 6. Capacity table
