Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 24,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 19.70 3.20 19.23 3.27 18.76 3.33 18.29 3.40 17.82 3.47
14 12 23.97 3.25 23.40 3.31 22.83 3.38 22.26 3.45 21.69 3.52
23 19 27.67 3.29 27.01 3.36 26.35 3.43 25.69 3.50 25.03 3.57
32 28 29.42 3.10 28.72 3.17 28.02 3.23 27.32 3.30 26.62 3.36
41 37 30.84 3.07 30.11 3.14 29.37 3.20 28.64 3.26 27.90 3.33
47 43 32.56 3.23 31.78 3.30 31.01 3.36 30.23 3.43 29.46 3.50
50 47 33.09 3.22 32.30 3.29 31.52 3.35 30.73 3.42 29.94 3.49
59 50 34.69 3.19 33.86 3.25 33.03 3.32 32.21 3.39 31.38 3.45
68 59 35.26 2.75 34.42 2.81 33.58 2.86 32.74 2.92 31.91 2.98
75 65 37.23 2.74 36.34 2.79 35.46 2.85 34.57 2.91 33.68 2.96
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 5.77 3.20 5.64 3.27 5.50 3.33 5.36 3.40 5.22 3.47
-10.0 -11.1 7.03 3.25 6.86 3.31 6.69 3.38 6.52 3.45 6.36 3.52
-5.0 -7.2 8.11 3.29 7.92 3.36 7.72 3.43 7.53 3.50 7.34 3.57
0.0 -2.2 8.62 3.10 8.42 3.17 8.21 3.23 8.01 3.30 7.80 3.36
5.0 2.8 9.04 3.07 8.82 3.14 8.61 3.20 8.39 3.26 8.18 3.33
8.3 6.1 9.54 3.23 9.32 3.30 9.09 3.36 8.86 3.43 8.63 3.50
10.0 8.3 9.70 3.22 9.47 3.29 9.24 3.35 9.01 3.42 8.77 3.49
15.0 10.0 10.17 3.19 9.92 3.25 9.68 3.32 9.44 3.39 9.20 3.45
20.0 15.0 10.34 2.75 10.09 2.81 9.84 2.86 9.60 2.92 9.35 2.98
23.9 18.3 10.91 2.74 10.65 2.79 10.39 2.85 10.13 2.91 9.87 2.96
 Indoor units: 7,000 Btu + 7,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 22.93 3.18 22.38 3.24 21.84 3.31 21.29 3.38 20.75 3.44
14 12 27.91 3.22 27.24 3.29 26.58 3.36 25.92 3.43 25.25 3.49
23 19 32.21 3.27 31.45 3.34 30.68 3.41 29.91 3.47 29.14 3.54
32 28 34.25 3.08 33.44 3.15 32.62 3.21 31.81 3.28 30.99 3.34
41 37 35.90 3.05 35.05 3.11 34.19 3.18 33.34 3.24 32.48 3.30
47 43 37.91 3.21 37.00 3.27 36.10 3.34 35.20 3.41 34.30 3.47
50 47 38.52 3.20 37.61 3.26 36.69 3.33 35.77 3.40 34.86 3.46
59 50 40.38 3.17 39.42 3.23 38.46 3.30 37.50 3.36 36.54 3.43
68 59 41.05 2.73 40.08 2.79 39.10 2.84 38.12 2.90 37.14 2.96
75 65 43.34 2.72 42.31 2.77 41.28 2.83 40.24 2.89 39.21 2.94
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 6.72 3.18 6.56 3.24 6.40 3.31 6.24 3.38 6.08 3.44
-10.0 -11.1 8.18 3.22 7.98 3.29 7.79 3.36 7.60 3.43 7.40 3.49
-5.0 -7.2 9.44 3.27 9.22 3.34 8.99 3.41 8.77 3.47 8.54 3.54
0.0 -2.2 10.04 3.08 9.80 3.15 9.56 3.21 9.32 3.28 9.08 3.34
5.0 2.8 10.52 3.05 10.27 3.11 10.02 3.18 9.77 3.24 9.52 3.30
8.3 6.1 11.11 3.21 10.84 3.27 10.58 3.34 10.32 3.41 10.05 3.47
10.0 8.3 11.29 3.20 11.02 3.26 10.75 3.33 10.48 3.40 10.22 3.46
15.0 10.0 11.84 3.17 11.55 3.23 11.27 3.30 10.99 3.36 10.71 3.43
20.0 15.0 12.03 2.73 11.75 2.79 11.46 2.84 11.17 2.90 10.89 2.96
23.9 18.3 12.70 2.72 12.40 2.77 12.10 2.83 11.80 2.89 11.49 2.94
- 282 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
