Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 7,000 Btu + 18,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 24.84 3.58 24.24 3.65 23.65 3.73 23.06 3.80 22.47 3.88
14 12 30.23 3.63 29.51 3.71 28.79 3.78 28.07 3.86 27.35 3.93
23 19 34.89 3.68 34.06 3.76 33.23 3.84 32.40 3.91 31.57 3.99
32 28 37.10 3.47 36.22 3.54 35.33 3.62 34.45 3.69 33.57 3.76
41 37 38.89 3.43 37.96 3.51 37.04 3.58 36.11 3.65 35.18 3.72
47 43 41.06 3.61 40.08 3.68 39.10 3.76 38.12 3.84 37.15 3.91
50 47 41.73 3.60 40.73 3.67 39.74 3.75 38.75 3.82 37.75 3.90
59 50 43.74 3.56 42.70 3.64 41.65 3.71 40.61 3.79 39.57 3.86
68 59 44.46 3.07 43.41 3.14 42.35 3.20 41.29 3.27 40.23 3.33
75 65 46.94 3.06 45.82 3.12 44.71 3.19 43.59 3.25 42.47 3.32
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.28 3.58 7.11 3.65 6.93 3.73 6.76 3.80 6.59 3.88
-10.0 -11.1 8.86 3.63 8.65 3.71 8.44 3.78 8.23 3.86 8.02 3.93
-5.0 -7.2 10.23 3.68 9.98 3.76 9.74 3.84 9.49 3.91 9.25 3.99
0.0 -2.2 10.87 3.47 10.61 3.54 10.36 3.62 10.10 3.69 9.84 3.76
5.0 2.8 11.40 3.43 11.13 3.51 10.85 3.58 10.58 3.65 10.31 3.72
8.3 6.1 12.03 3.61 11.75 3.68 11.46 3.76 11.17 3.84 10.89 3.91
10.0 8.3 12.23 3.60 11.94 3.67 11.65 3.75 11.36 3.82 11.06 3.90
15.0 10.0 12.82 3.56 12.51 3.64 12.21 3.71 11.90 3.79 11.60 3.86
20.0 15.0 13.03 3.07 12.72 3.14 12.41 3.20 12.10 3.27 11.79 3.33
23.9 18.3 13.76 3.06 13.43 3.12 13.10 3.19 12.78 3.25 12.45 3.32
 Indoor units: 7,000 Btu + 7,000 Btu + 24,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 26.04 3.76 25.42 3.84 24.80 3.92 24.18 3.99 23.56 4.07
14 12 31.70 3.81 30.94 3.89 30.19 3.97 29.43 4.05 28.68 4.13
23 19 36.58 3.87 35.71 3.95 34.84 4.03 33.97 4.11 33.10 4.19
32 28 38.90 3.65 37.98 3.72 37.05 3.80 36.12 3.87 35.20 3.95
41 37 40.78 3.61 39.81 3.68 38.84 3.76 37.86 3.83 36.89 3.91
47 43 43.05 3.79 42.03 3.87 41.00 3.95 39.98 4.03 38.95 4.11
50 47 43.75 3.78 42.71 3.86 41.67 3.94 40.63 4.02 39.59 4.10
59 50 45.86 3.74 44.77 3.82 43.68 3.90 42.59 3.98 41.49 4.06
68 59 46.63 3.23 45.52 3.30 44.41 3.36 43.30 3.43 42.19 3.50
75 65 49.22 3.21 48.05 3.28 46.88 3.35 45.71 3.42 44.54 3.48
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.63 3.76 7.45 3.84 7.27 3.92 7.09 3.99 6.91 4.07
-10.0 -11.1 9.29 3.81 9.07 3.89 8.85 3.97 8.63 4.05 8.41 4.13
-5.0 -7.2 10.72 3.87 10.47 3.95 10.21 4.03 9.96 4.11 9.70 4.19
0.0 -2.2 11.40 3.65 11.13 3.72 10.86 3.80 10.59 3.87 10.32 3.95
5.0 2.8 11.95 3.61 11.67 3.68 11.38 3.76 11.10 3.83 10.81 3.91
8.3 6.1 12.62 3.79 12.32 3.87 12.02 3.95 11.72 4.03 11.42 4.11
10.0 8.3 12.82 3.78 12.52 3.86 12.21 3.94 11.91 4.02 11.60 4.10
15.0 10.0 13.44 3.74 13.12 3.82 12.80 3.90 12.48 3.98 12.16 4.06
20.0 15.0 13.67 3.23 13.34 3.30 13.01 3.36 12.69 3.43 12.36 3.50
23.9 18.3 14.43 3.21 14.08 3.28 13.74 3.35 13.40 3.42 13.05 3.48
- 283 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu ASU18RLF Specifications
