Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 9,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 22.23 3.21 21.70 3.27 21.17 3.34 20.64 3.41 20.11 3.47
14 12 27.06 3.25 26.41 3.32 25.77 3.39 25.13 3.46 24.48 3.52
23 19 31.23 3.30 30.49 3.37 29.74 3.44 29.00 3.51 28.26 3.57
32 28 33.21 3.11 32.42 3.18 31.63 3.24 30.84 3.31 30.05 3.37
41 37 34.81 3.08 33.98 3.14 33.15 3.21 32.32 3.27 31.49 3.33
47 43 36.75 3.24 35.88 3.30 35.00 3.37 34.13 3.44 33.25 3.50
50 47 37.35 3.23 36.46 3.29 35.57 3.36 34.68 3.43 33.79 3.49
59 50 39.15 3.19 38.22 3.26 37.29 3.33 36.35 3.39 35.42 3.46
68 59 39.80 2.75 38.85 2.81 37.91 2.87 36.96 2.93 36.01 2.98
75 65 42.02 2.74 41.02 2.80 40.02 2.86 39.02 2.91 38.02 2.97
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 6.52 3.21 6.36 3.27 6.21 3.34 6.05 3.41 5.90 3.47
-10.0 -11.1 7.93 3.25 7.74 3.32 7.55 3.39 7.36 3.46 7.18 3.52
-5.0 -7.2 9.15 3.30 8.94 3.37 8.72 3.44 8.50 3.51 8.28 3.57
0.0 -2.2 9.73 3.11 9.50 3.18 9.27 3.24 9.04 3.31 8.81 3.37
5.0 2.8 10.20 3.08 9.96 3.14 9.72 3.21 9.47 3.27 9.23 3.33
8.3 6.1 10.77 3.24 10.51 3.30 10.26 3.37 10.00 3.44 9.75 3.50
10.0 8.3 10.95 3.23 10.69 3.29 10.43 3.36 10.16 3.43 9.90 3.49
15.0 10.0 11.47 3.19 11.20 3.26 10.93 3.33 10.65 3.39 10.38 3.46
20.0 15.0 11.67 2.75 11.39 2.81 11.11 2.87 10.83 2.93 10.55 2.98
23.9 18.3 12.32 2.74 12.02 2.80 11.73 2.86 11.44 2.91 11.14 2.97
 Indoor units: 7,000 Btu + 9,000 Btu + 14,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 24.52 3.40 23.93 3.47 23.35 3.54 22.77 3.61 22.18 3.68
14 12 29.84 3.45 29.13 3.52 28.42 3.59 27.71 3.66 27.00 3.73
23 19 34.44 3.50 33.62 3.57 32.80 3.64 31.98 3.71 31.16 3.79
32 28 36.63 3.30 35.75 3.36 34.88 3.43 34.01 3.50 33.14 3.57
41 37 38.39 3.26 37.48 3.33 36.56 3.40 35.65 3.46 34.73 3.53
47 43 40.53 3.43 39.57 3.50 38.60 3.57 37.64 3.64 36.67 3.71
50 47 41.19 3.42 40.21 3.49 39.23 3.56 38.25 3.63 37.27 3.70
59 50 43.18 3.38 42.15 3.45 41.12 3.53 40.09 3.60 39.07 3.67
68 59 43.90 2.92 42.85 2.98 41.81 3.04 40.76 3.10 39.72 3.16
75 65 46.34 2.91 45.24 2.97 44.14 3.03 43.03 3.09 41.93 3.15
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.19 3.40 7.01 3.47 6.84 3.54 6.67 3.61 6.50 3.68
-10.0 -11.1 8.75 3.45 8.54 3.52 8.33 3.59 8.12 3.66 7.91 3.73
-5.0 -7.2 10.09 3.50 9.85 3.57 9.61 3.64 9.37 3.71 9.13 3.79
0.0 -2.2 10.73 3.30 10.48 3.36 10.22 3.43 9.97 3.50 9.71 3.57
5.0 2.8 11.25 3.26 10.98 3.33 10.72 3.40 10.45 3.46 10.18 3.53
8.3 6.1 11.88 3.43 11.60 3.50 11.31 3.57 11.03 3.64 10.75 3.71
10.0 8.3 12.07 3.42 11.79 3.49 11.50 3.56 11.21 3.63 10.92 3.70
15.0 10.0 12.65 3.38 12.35 3.45 12.05 3.53 11.75 3.60 11.45 3.67
20.0 15.0 12.87 2.92 12.56 2.98 12.25 3.04 11.95 3.10 11.64 3.16
23.9 18.3 13.58 2.91 13.26 2.97 12.94 3.03 12.61 3.09 12.29 3.15
- 284 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
