Fujitsu ASU18RLF Design & Technical Manual

 Indoor units: 7,000 Btu + 9,000 Btu + 18,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 25.53 3.68 24.93 3.76 24.32 3.84 23.71 3.91 23.10 3.99
14 12 31.08 3.74 30.34 3.81 29.60 3.89 28.86 3.97 28.12 4.05
23 19 35.87 3.79 35.02 3.87 34.16 3.95 33.31 4.03 32.45 4.11
32 28 38.14 3.57 37.24 3.65 36.33 3.72 35.42 3.80 34.51 3.87
41 37 39.98 3.53 39.03 3.61 38.08 3.68 37.13 3.76 36.17 3.83
47 43 42.21 3.72 41.21 3.79 40.20 3.87 39.20 3.95 38.19 4.02
50 47 42.90 3.70 41.88 3.78 40.86 3.86 39.84 3.94 38.81 4.01
59 50 44.97 3.67 43.90 3.75 42.83 3.82 41.76 3.90 40.68 3.97
68 59 45.72 3.16 44.63 3.23 43.54 3.30 42.45 3.36 41.36 3.43
75 65 48.26 3.15 47.11 3.22 45.96 3.28 44.82 3.35 43.67 3.41
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.48 3.68 7.31 3.76 7.13 3.84 6.95 3.91 6.77 3.99
-10.0 -11.1 9.11 3.74 8.89 3.81 8.67 3.89 8.46 3.97 8.24 4.05
-5.0 -7.2 10.51 3.79 10.26 3.87 10.01 3.95 9.76 4.03 9.51 4.11
0.0 -2.2 11.18 3.57 10.91 3.65 10.65 3.72 10.38 3.80 10.11 3.87
5.0 2.8 11.72 3.53 11.44 3.61 11.16 3.68 10.88 3.76 10.60 3.83
8.3 6.1 12.37 3.72 12.08 3.79 11.78 3.87 11.49 3.95 11.19 4.02
10.0 8.3 12.57 3.70 12.27 3.78 11.97 3.86 11.68 3.94 11.38 4.01
15.0 10.0 13.18 3.67 12.87 3.75 12.55 3.82 12.24 3.90 11.92 3.97
20.0 15.0 13.40 3.16 13.08 3.23 12.76 3.30 12.44 3.36 12.12 3.43
23.9 18.3 14.15 3.15 13.81 3.22 13.47 3.28 13.13 3.35 12.80 3.41
 Indoor units: 7,000 Btu + 12,000 Btu + 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 24.52 3.54 23.93 3.61 23.35 3.69 22.77 3.76 22.18 3.84
14 12 29.84 3.59 29.13 3.67 28.42 3.74 27.71 3.82 27.00 3.89
23 19 34.44 3.64 33.62 3.72 32.80 3.79 31.98 3.87 31.16 3.95
32 28 36.63 3.43 35.75 3.51 34.88 3.58 34.01 3.65 33.14 3.72
41 37 38.39 3.40 37.48 3.47 36.56 3.54 35.65 3.61 34.73 3.68
47 43 40.53 3.57 39.57 3.65 38.60 3.72 37.64 3.79 36.67 3.87
50 47 41.19 3.56 40.21 3.63 39.23 3.71 38.25 3.78 37.27 3.86
59 50 43.18 3.53 42.15 3.60 41.12 3.67 40.09 3.75 39.07 3.82
68 59 43.90 3.04 42.85 3.10 41.81 3.17 40.76 3.23 39.72 3.29
75 65 46.34 3.03 45.24 3.09 44.14 3.15 43.03 3.22 41.93 3.28
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 7.19 3.54 7.01 3.61 6.84 3.69 6.67 3.76 6.50 3.84
-10.0 -11.1 8.75 3.59 8.54 3.67 8.33 3.74 8.12 3.82 7.91 3.89
-5.0 -7.2 10.09 3.64 9.85 3.72 9.61 3.79 9.37 3.87 9.13 3.95
0.0 -2.2 10.73 3.43 10.48 3.51 10.22 3.58 9.97 3.65 9.71 3.72
5.0 2.8 11.25 3.40 10.98 3.47 10.72 3.54 10.45 3.61 10.18 3.68
8.3 6.1 11.88 3.57 11.60 3.65 11.31 3.72 11.03 3.79 10.75 3.87
10.0 8.3 12.07 3.56 11.79 3.63 11.50 3.71 11.21 3.78 10.92 3.86
15.0 10.0 12.65 3.53 12.35 3.60 12.05 3.67 11.75 3.75 11.45 3.82
20.0 15.0 12.87 3.04 12.56 3.10 12.25 3.17 11.95 3.23 11.64 3.29
23.9 18.3 13.58 3.03 13.26 3.09 12.94 3.15 12.61 3.22 12.29 3.28
- 285 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU36RLXFZ1 OUTDOOR UNIT AOU36RLXFZ1

Fujitsu ASU18RLF Specifications

General

Brand	Fujitsu
Model	ASU18RLF
Category	Air Conditioner
Language	English
