612011.05.20
OUTDOOR UNIT
ACCESSORIES
Use
For drain piping work
Q'ty
1
5
Name and Shape
Drain pipe
Drain cap
For use when connecting
models 9-12 to outdoor port A
1
Adapter assy
12.7 mm 9.52 mm
(1/2 in.) (3/8 in.)
