8-3. Current release control
The rotation number of compressor is controlled so that the outdoor unit input current does not ex-
ceeds current limit value set according to the outdoor temperature.
The rotation number of compressor returns according to the operation mode, when the current be-
comes lower than the release value.
¢ AOUH18LMAS1
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
125.6 °F (52 °C) ≤ Ta 8.0 A 7.5 A
122.0 °F (50 °C) ≤ Ta < 125.6 °F (52 °C) 10.0 A 9.5 A
Ta < 122.0 °F (50 °C) 12.5 A 12.0 A
Heating
60.8 °F (16 °C) ≤ Ta 10.0 A 9.5 A
53.6 °F (12 °C) ≤ Ta < 60.8 °F (16 °C) 11.5 A 11.0 A
Ta < 53.6 °F (12 °C) 13.0 A 12.5 A
¢ AOUH24LMAS1
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
125.6 °F (52 °C) ≤ Ta 8.0 A 7.5 A
122.0 °F (50 °C) ≤ Ta < 125.6 °F (52 °C) 10.0 A 9.5 A
114.8 °F (46 °C) ≤ Ta < 122.0 °F (50 °C) 13.0 A 12.5 A
107.6 °F (42 °C) ≤ Ta < 114.8 °F (46 °C) 14.0 A 13.5 A
Ta < 107.6 °F (42 °C) 14.5 A 14.0 A
Heating
68.0 °F (20 °C) ≤ Ta 11.0 A 10.5 A
60.8 °F (16 °C) ≤ Ta < 68.0 °F (20 °C) 13.0 A 12.5 A
Ta < 60.8 °F (16 °C) 15.0 A 14.5 A
8-4. Compressor temperature protection
→hen the compressor temperature sensor detects higher than the trigger condition below, the com-
pressor is stopped. →hen the compressor temperature sensor detects the release condition, the pro-
tection is released.
Trigger condition 226.4°F (108°C)
Release condition
176.0°F (80°C)
(3 minutes after compressor stop)
8-5. High pressure protection
Trigger condition
Pressure switch: Off (Open: Higher than 4.2 MPa)
Compressor stop
Release condition
Pressure switch: On (Close: Lower than 3.2 MPa)
(3 minutes after compressor stop)
Compressor restart
8-3. Current release control - (04-32) - 8. Various protections
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
