DIMENSIONS
Models : AS*A07LGC / AO*R07LGC
AS*A09LGC / AO*R09LGC
AS*A12LGC / AO*R12LGC
02-01
(unit : mm)
INDOOR UNIT
OUTDOOR UNIT
260
540
198
790
660290
